Introduction

Congratulations on your purchase of a Revolabs digital wireless microphone system! This
system utilizes 1.9 GHz DECT technology, and high band-width audio from multiple
wireless microphones, enabling clear, reliable, un-tethered communications in recording,
audio/video conferencing, speech recognition, VOIP communications, sound re-
enforcement as well as many other environments requiring clear audio capture.
The Revolabs Executive HD ™ Wireless Microphone System is a second generation
technology that contains substantial improvements to audio performance, microphone
density and user interface/control improvements including Ethernet interface. The
Executive HD system is a unique marriage of innovative technology and ergonomic design,
employing Multi-Carrier, Time Division Multiple Access and Time Division Duplex
(MC/TDMA/TDD) radio transmissions both to and from the microphone.
This technology allows the microphones to co-exist with other wireless products such as
wireless LANs (802.11b&g), and includes digital encryption technology to ensure secure
communications.

System Components

Depending on which system you've purchased, your Revolabs Executive HD ™ System
package contains the following:
Rack mountable 4 or 8 channel Base Station
Microphone Docking Station
HD wireless microphones, (earpieces and lanyards with wearable microphone only).
The Base Station houses the processor and one end of the wireless connection. It features
either one pair (4 Mic system) or two pairs (8 Mic system) of diversity antennas and offers
individual line-level or mic-level audio in/out for each microphone channel. This allows for
external audio processing such as:
