- Page 1 REVOLABS Elite ™ Wired Microphones Installation and Operation Guide Models: 01-EWM-DR-BLK 01-EWM-OM-BLK 01-EWM-DR-WHT 01-EWM-OM-WHT 01-EWM-DR-BNI 01-EWM-OM-BNI...
-
Page 2: Introduction
© 2014 REVOLABS, INC. All rights reserved. No part of this document may be reproduced in any form or by any means without express written permission from Revolabs, Inc. Product specifications are subject to change without notice. R e v o l a b s E i l t e W i r e d M i c r o p h o n e I n s t a l l a t i o n a n d O p e r a t i o n G u i d e 1 0 - E X E C W M G U I D E - E N N O V E M B E R 2 0 1 4 ( R e v 1 . - Page 3 Introduction Congratulations on your purchase of the Revolabs Elite™ Wired Microphone. This microphone utilizes state of the art technology providing high bandwidth audio and enabling clear, reliable audio capture for your applications. Please read this documentation carefully and follow the instructions before...
-
Page 4: Safety And General Information
Safety and General Information Please read the following information to ensure safe and efficient use of your Revolabs system. FCC Notice to Users This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Industry Canada Notice To Users
2004/108/EC, and RoHS II Directive 2011/65/EU. Model Number: Description: 01-EWM-DR Elite Wired Directional Mic 01-EWM-OM Elite Wired Omnidirectional Mic Any unauthorized modification of the products voids this Declaration. For a copy of the original signed declaration of conformity, please contact Revolabs at the above address. -
Page 6: Weee Notification
• Do not open the casings of any of the Elite Wired Microphones. • Do not use any other accessories than Revolabs’ originals intended for use with this product. Use of non-original accessories may result in loss of performance, damage to the product, fire, electric shock or injury. -
Page 7: Table Of Contents
Content Introduction ......................... 2 Safety and General Information ................... 4 FCC Notice to Users ....................4 Industry Canada Notice to Users ................5 Notice to European Customers ................. 5 WEEE Notification ....................6 Safety Warnings ......................6 Content ........................7 Components ........................ -
Page 8: Components
Components Your Revolabs Elite Wired Microphone comes with a 15’ (4.5 m) cable attached to connect it to a phantom powered microphone input of a digital signal processor (DSP), or other audio devices. The packaging includes the microphone with cable and a short installation documentation. -
Page 9: Installation
Black – Negative (-) Shield - Ground The Revolabs Elite Wired Microphone has a 15 feet cable attached that hosts three wires. The three wires are red, black, and the shield/ground. Connect the red wire to the positive (+) microphone input of the DSP or audio equipment you use with the microphone. -
Page 10: Microphones
Microphones Revolabs Elite Wired Microphones come in two different versions: • Revolabs Elite Omni-directional Tabletop Wired Boundary Microphone • Revolabs Elite Uni-directional Tabletop Wired Boundary Microphone The Elite Omni-Directional Wired Tabletop Boundary Microphones The Elite Omni-directional Wired Tabletop Boundary Microphones enable multiple conference attendees to use a single microphone. -
Page 11: The Elite Directional Wired Tabletop Boundary Microphones
To use the Elite Omni-Directional Tabletop Microphone, it should be centered on the table within 2 to 6 feet (0.6 to 2m) from people speaking and do not need to be pointing any particular direction as they pick up sound from all directions. -
Page 12: Warranty
Revolabs, Inc. warrants this product to be free of manufacturing defects. Repair or replacement of any defective part or unit (at the discretion of the Seller) will be free of charge for the period defined in the Revolabs Professional Products Limited Warranty. -
Page 13: Technical Support
Technical Support If you are experiencing technical problems or if you have questions about the operation, configuration or troubleshooting of any Revolabs product, please email support@revolabs.com or call 1-800-326-1088. Specifications Product Dimensions Microphone Dimensions Weight Omni-Directional Tabletop 3.125 x 3.125 x 1.125 in 6.6 oz. - Page 14 Microphone Polar Patterns Elite Omni-Directional Wired Tabletop Microphone : Elite Directional Wired Tabletop Microphone:...
- Page 15 R e v o l a b s E i l t e W i r e d M i c r o p h o n e I n s t a l l a t i o n a n d O p e r a t i o n G u i d e 1 0 - E X E C W M G U I D E - E N N O V E M B E R 2 0 1 4 ( R e v 1 .
