Revolabs 01-HDEXEC Installation And Operation Manual page 18

String Table:
Argument Command
set mute
get mute
batt
val mute
batt
Channel #:
The options for the <Channel#> portion of the serial strings are ―1-8‖ since each Base station can
only control up to 8 channels of an Executive HD microphone system. The <channel#> corresponds
to the physical channel that the microphone is paired to on the front of each Base Station.
A <Channel#> of ―A‖ will enable or disable the Master Mute mode. This command must only be sent
to the Base Station that is set to ―Local‖. ―Remote‖ Base Stations will not accept the command.
Examples:
The following strings would unmute microphone channel 3:
Command: set mute ch 3 0
The following strings would turn on the Master Mute:
Command: set mute ch A 1
The following strings would retrieve the battery status of mic 5 @ 100%:
Command: get batt ch 5
Channel# Value
1-8 = ch 1-8 0 = off
A = Master Mute 1 = on
1-8 = ch 1-8
A = Master Mute
1-8 = ch 1-8
1-8 = ch 1-8 0 = off
A = Master Mute 1 = self mute on (TT Master Mute Mode)
2 = on
3 = unknown (Mic not connected)
1-8 = ch 1-8 0 = empty
1 = 25%
2 = 50%
3 = 75%
4 = 100%
Return: val mute ch 3 0
Return: val mute ch A 1
Return: val batt ch 5 4
- 15 -
