To Install the Base Station:
1. Plug the power cord into an appropriate outlet.
2. Turn the fuse-protected power switch on the back panel to Reset.
The LCD on the front panel will illuminate.
3. Attach the diversity antennas (2 or 4 SMA female connectors).
Revolabs Executive HD™ Audio Connections
There are (8) 3.5mm mini-Phoenix input and (8) 3.5mm mini-Phoenix output ports on the back panel
of the unit (four on the 4-channel system) providing access to each channel's audio signal.
The provided mini-Phoenix connectors are designed for easy wiring. The three terminals (from left to
right) correspond to positive +, negative -, and shielded ground .
To connect audio In/Out on the Executive HD
1. Use the screws on top of the connector to first loosen the terminals.
2. Insert an appropriate 3 conductor cable (3 separate conductors, or 2 conductors and shield) into
the terminals.
3. Tighten the screw to secure the cable.
4. Push the connector onto the pins centered under the desired input or output port until firmly
secured.
There are four or eight output channels representing a separate channel for each microphone.
Accordingly, there are four or eight input channels to the unit. The microphone output connectors
need to be attached to the line-level (0dBu) input connectors of an audio mixer. PHANTOM POWER
MUST BE OFF.
The Base Station input connectors (also 0dBu) may then be attached to mixer channel outputs.
Because the system is full-duplex, the input connections provide the ability to hear program audio
using a 2.5mm earpiece attached to the microphone (supplied with the wearable microphone).
Depending on the application, it is possible to feed a single mixed channel back to all earpieces or,
alternatively, each user can receive a separate and unique channel. This would allow for translation,
personal hearing assistance or other services to be incorporated into an application.
Configuring the Executive HD
Each Revolabs Executive HDTM Base Station must be configured properly prior to use. Accurate
configuration is dependent on several variables such as:
1. How many Executive HD systems are being used together in proximity?
2. What type of 3
3. How large is the room?
4. Is Line Level or Mic Level signal required?
5. How do the mic mutes need to function?
TM
Base Station
rd
party mute control is being used?
