The Display View consists of two areas: The lower Hardware Area displays the
AUDIO KONTROL 1 hardware top panel. In the upper Information Area, information
text is displayed, depending on the mouse position within the Hardware Area. If you
position the mouse over one of the elements in the Hardware Area, the Information
Area will update to display all mapping information for this particular Controller.

7.4.4. The Assign View

The Assign View allows you to precisely define the action of each Controller on the
hardware's top panel. As we described in the previous section 7.3, each human
interaction with a Controller induces a hardware action that is translated by the Driver
into a hardware event, itself transformed by the Mapping Application into a software
event sent to the corresponding application. If this sounds new to you, please refer
to the above-mentioned section.
The Assign View is the place where you configure this translation between hardware
actions and software events.
If the Assign View is not active, click on the Assign Button in the Application Control
Bar (if there is no Assign Button in the Bar, it means that you are already in the
Assign View.)
Like the Display View, the Assign View is split into two areas: the upper Selection
Area and the lower Definition Area. Basically, the Selection Area specifies the element
whose mapping is set in the Definition Area.
AUDIO KONTROL 1 – 89
