Monitoring Menu - Native Instruments AUDIO KONTROL 1 Operation Manual

►
Open Page: Provides a list of pages similar to the Page Select Menu within the
Application Control Bar.
►
Save Page: Saves the Page with its current name, like the Save Button within
the interface. If the Page was loaded from the Factory Pages folder, a dialog
comes up informing about the fact that the page will be saved to the User
Pages folder. If you agree, choose Save to User Content; if not, choose Cancel.
If the Page's current name is New (i.e. it was created by the New Page com-
mand), the command is similar to the Save Page As... command.
►
Save Page As...: Brings up a dialog that lets you enter a name for the Page. A
warning dialog asks for confirmation if the chosen filename is already used;
you then can choose whether to Replace the Page already existing or to Cancel
and choose another name.
►
Delete Page...: This entry is inactive if a Factory Page is loaded. If a User Page
is loaded, it brings up a warning dialog asking for confirmation (with the self-
explaining options Delete and Cancel). After deletion, the file "New.xml" is
loaded automatically.
►
Audio Settings...: Opens the Driver Control Panel (like the Driver Button in the
Application Control Bar). For more info in the Driver Control Panel, see section
7.2.
►
Exit: Quits the Mapping Application. Note that the AUDIO KONTROL 1's top
panel remote control will then be deactivated, since it needs the Mapping
Application to be running in order to function properly.

Monitoring Menu

This menu allows you to select the output pair from the four Main Output Jacks
to which the Direct Monitoring signal has to be sent. You can choose pair 1/2, 3/4, or
both. (For more info on how to use Direct Monitoring, see sections 3.1.1 for the
theory and 6.1 for the practice.).
AUDIO KONTROL 1 – 85
