Native Instruments AUDIO KONTROL 1 Operation Manual page 67

Knob
Morph Left/Right
Main Layer
(CC 24)
Left Layer
Middle Layer
Morph Up/Down
Right Layer
(CC 25)
6.3.2. Creating Your Own Assignments
Note that it makes no sense to assign a command to the Left Button in the Left
Layer: the expression "Left Layer" means precisely that the Left Button is already
pressed, changing the behavior of the other Controllers. The same applies to the
Middle Button in the Middle Layer and to the Right Button in the Right Layer.
Activate, for example, the Page dealing with the effects parameters. To do this,
bring the Mapping Application to the front, open the Page Select menu by clicking
on it, and select the Page "MIDI Demo Page". The mappings in this Page can be
summarized as follows:
Knob
Main Layer Master Volume
Left Layer Chorus Dry/Wet
Middle Layer Delay Dry/Wet
Right Layer Reverb Dry/ Wet Dry/ Wet
As you can see, each Layer is in charge of one effect:
►
the Main Layer (no Button held) only controls the overall Volume
►
the Left Layer (Left Button held) controls some Chorus parameters
►
the Middle Layer (Middle Button held) controls some Delay parameters
►
the Right Layer (Right Button held) controls some Reverb parameters
Left Button Middle Button
1st Button On/Off 2nd Button On/Off
Left Button Middle Button
Modifier Modifier
Decrease Depth
Decrease Time
Decrease Time Increase Time
Right Button
Modifier
Right Button
Modifier
Increase Depth
Increase Time
AUDIO KONTROL 1 – 67
