Info Leds - Native Instruments AUDIO KONTROL 1 Operation Manual

19: Controller Knob, 20: Left Button, 21: Middle Button, 22: Right Button
The use of these four Controllers will be extensively explained in the next sections.
They are the core of the remote control of AUDIO KONTROL 1.

23, 24: Info LEDs

These LEDs inform you about various aspects of AUDIO KONTROL 1.
►
48V: indicates the state of the Phantom Power Switch (18).
►
Input 1: indicates activity at the hardware's first audio input. It lights red if the
signal is clipped. In this case you should decrease the Input 1 level.
►
Input 2: indicates activity at the hardware's second audio input. It lights red if
the signal is clipped. In this case you should decrease the Input 2 level.
►
Output 1/2: indicates activity at the hardware's first audio output pair (Main Output
Jacks 1/2, 17).
►
Output 3/4: indicates activity at the hardware's second audio output pair (Main
Output Jacks 3/4, 17).
►
USB: indicates the USB connection state. If the connection is established it is
steadily lit. It blinks while the components are initializing.
►
MIDI In: indicates if there are MIDI messages being received at the hardware's
MIDI Input (15).
►
MIDI Out: indicates if there are MIDI messages being sent from the hardware's
MIDI Output (15).
►
Monitor 1/2: indicates if the direct monitoring signal is being sent to the first
audio output pair (Main Output Jacks 1/2, (17)).
►
Monitor 3/4: indicates if the direct monitoring signal is being sent to the second
audio output pair (Main Output Jacks 3/4, (17)).
AUDIO KONTROL 1 – 17
