When you have activated all desired MIDI devices, close the Audio and MIDI
Settings dialog and continue within KORE PLAYER:
►
In KORE PLAYER, click the Control Tab to display the internal MIDI Menu.
►
From the Input Menu, select the "Audio Kontrol 1 Virtual MIDI In" entry.
You have just selected the AUDIO KONTROL 1 as the MIDI remote control device for
KORE PLAYER. Now there's only one thing left to do: you need to tell KORE PLAYER
which of its actions you want to control from the AUDIO KONTROL 1. The easiest
way to do this is by selecting a pre-assigned Controller Page, as described in the
following section.
Four control elements are located on the AUDIO KONTROL 1 top panel; their
behavior is managed by the Mapping Application. The mapping system for the
hardware's four top panel Controllers is organized into the so-called Controller
Pages. A single Controller Page is a full set of assignments for the four Controllers
in the four Layers.
If this sounds new to you, we recommend you to read the relevant subsections in
section 2. The concept of Layers is extensively described in section 7.3 of this
manual.
AUDIO KONTROL 1 comes with plenty of Factory Pages for many applications, and
there is also one for KORE PLAYER. In order to make the AUDIO KONTROL 1's
remote control capabilities available in KORE PLAYER, you need to load the ap-
propriate Controller Page first. To get you started immediatly, we have prepared
a Controller Page for the AUDIO KONTROL 1's Mapping Application that lets you
manipulate the sound loaded in KORE PLAYER very effectively:
►
The AUDIO KONTROL 1's Left Button switches KORE PLAYER's Parameter
Button 1 (the leftmost button in the upper row) on and off.
►
The Middle Button does the same as above for Parameter Button 2 (which is
the button right beside Parameter Button 1).
