Asio Direct Monitoring - Native Instruments AUDIO KONTROL 1 Operation Manual

6.1.4 ASIO™ Direct Monitoring
ASIO™ Direct Monitoring is a combination of the two former methods. The monitor-
ing is done directly in AUDIO KONTROL 1, so that the monitoring signal doesn't
pass through your recording software (thus avoiding potential latency issues), but
you can still activate the monitoring from within the recording software, also giv-
ing you the benefit of its various monitoring modes. Since the monitoring signal
doesn't go through your recording software, you won't be able to apply any EQ or
effects to it.
To activate ASIO™ Direct Monitoring, open the Device Setup dialog in the Devices menu
and use the Direct Monitoring checkbox on the VST Audio System page.
To enable the voice track monitoring, you need to activate its Monitor button, on the
Mixer, in the main project window or in the track's Inspector:
In the Mapping Application's Monitor menu, you can then select which output the
input signal will be monitored from (see above).
Cubase® LE also provides you with automatic monitoring options. For more info,
please refer to the Cubase® LE manual included as a PDF in the installation
folder.
AUDIO KONTROL 1 – 55
