User's Manual
LPN 1736
Omni-Directional Laser Scanner
25-ULPNMU01-02
Keyboard Wedge Interface
USB Interface
RS232 Interface
8 Olympic Drive
Orangeburg, NY 10962
Tel 800.636.0090
Fax 845.365.1251
www.opticonUSA.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPN 1736 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Opticon LPN 1736

Summary of Contents for Opticon LPN 1736

  • Page 1 User’s Manual LPN 1736 Omni-Directional Laser Scanner 25-ULPNMU01-02 Keyboard Wedge Interface USB Interface RS232 Interface 8 Olympic Drive Orangeburg, NY 10962 Tel 800.636.0090 Fax 845.365.1251 www.opticonUSA.com...

  • Page 2: Table Of Contents

    Manual No. 25-ULPNMU01-01 Getting Started General Information Unpacking Parts of Scanner Attaching Scanner to Adjustable Stand Opticon Customer Service and Support Programming Bar Codes Start/Stop Programming Bar Code Scanning Template Chapter 1 Keyboard Wedge Interface Installing and Setting Up Reset All Defaults – Wedge...
  • Page 3 C Default Settings D. Settings for Ruby VeriFone NOTICE Opticon has taken every step to ensure that the information included in this manual is accurate; however we reserve the right to change any specification at any time without prior notice.

  • Page 4: Getting Started

    Remove the scanner from its packaging and inspect it for damage. Save the carton and packing material. If the scanner was damaged in transit, call the dealer or distributor from whom you purchased it. If you purchased it directly from Opticon, call Opticon Customer Service Dept. at 800-636-0090.

  • Page 5: Parts Of Scanner

    To mount the scanner to the stand, insert the plastic screw through the hole in the base of the scanner into the hole in the arm of the stand. Tighten. The cable clamp on the base can improve cable management.

  • Page 6: Opticon Customer Service And Support

    If you have any questions or need assistance with installing or programming your scanner call Opticon Customer Service Department at (800) 636-0090. Before you call, record the model number of the scanner. This information is located on the label near the connector end of the cable. Please have the scanner available plus some bar codes to scan.

  • Page 7: Programming Bar Codes

    LPN1736 Omni-Directional Laser Scanner Programming Bar Codes Opticon scanners are preprogrammed at the factory with default settings representing the settings most commonly used by our customers. In most applications, the scanner will work right out of the box without the need for additional programming.

  • Page 8: Scanning Template

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Scanning Template for Programming Cut and Remove this section to create a window Page 8...

  • Page 9: Keyboard Wedge Interface

    The host computer accepts these keystrokes as if they were typed on the keyboard. The host computer does not know if keystrokes come from the keyboard or the scanner. It treats all information it receives as if it came from the keyboard.

  • Page 10: Reset All Defaults - Wedge

    Manual No. 25-ULPNMU01-01 Reset All Defaults Opticon scanners are preprogrammed at the factory with default settings representing the settings most commonly used by our customers. In most applications, the scanner will work right out of the box without the need for additional programming. At any time, you can return a scanner to the factory defaults by scanning the “Start/Stop Programming...
  • Page 11 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner XT Keyboard Wedge PS2 Keyboard Wedge Page 11...

  • Page 12: Computer Type Selection

    The keyboard wedge interface of the LPN1736 is set to operate with an IBM AT (or compatible) style of personal computer. If your personal computer is different, place the scanner in the programming mode and scan the appropriate programming bar codes. IBM PC/XT...

  • Page 13: Intercharacter Delay

    Manual No. 25-ULPNMU01-01 Intercharacter Delay The scanner may send data faster than the computer or application program can accept it. This is called “keyboard buffer overrun”. If data appears to be missing, random read errors occur, or the scanner locks up and will not scan, experiment with the various keyboard timing options that follow;...
  • Page 14 Manual No. 25-ULPNMU01-01 Delay = 4 (LE) Delay = 6 (LG) LPN1736 Omni-Directional Laser Scanner Delay = 5 (LF) Delay = 7 (LH) Page 14...
  • Page 15 Manual No. 25-ULPNMU01-01 Delay = 8 (LI) Delay = 10 (LK) LPN1736 Omni-Directional Laser Scanner Delay = 9 (LJ) Page 15...

  • Page 16: Chapter 2 Rs232 Interface

    Installing and Setting Up The installation is as follows: 1. Plug the scanner into an RS232 port (such as COM 1) of the host PC. Insert the plug of the external power supply into the jack on the RS232 connector.

  • Page 17: Handshaking Protocol

    In most applications, the scanner will work right out of the box without the need for additional programming. At any time you can return the scanner back to the factory default settings by scanning the “Reset All Defaults -RS232” programming bar code. Remember that before scanning any programming codes, you must put the scanner into the programming mode by scanning the Start/Stop Programming Mode bar code.

  • Page 18: Handshaking

    Manual No. 25-ULPNMU01-01 Handshaking Protocols . . . continued ACK / NAK (P3) Flow Control Time Unlimited (I0) DEFAULT LPN1736 Omni-Directional Laser Scanner Xon / Xoff (ZG) Page 18...
  • Page 19 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Flow Control . . . Continued Flow Control = 100ms (I1) Flow Control = 100ms (I1) Flow Control = 200ms (I2) Flow Control = 200ms (I2) Flow Control = 400ms (I3) Flow Control = 400ms (I3)

  • Page 20: Baud Rate

    Manual No. 25-ULPNMU01-01 Baud Rate Baud Rate = 19200 (K7) Baud Rate = 9600 (K6) DEFAULT Baud Rate = 4800 (K5) LPN1736 Omni-Directional Laser Scanner Baud Rate = 19200 (K7) Baud Rate = 9600 (K6) DEFAULT Baud Rate = 4800 (K5)
  • Page 21 Baud Rate . . . continued Baud Rate = 2400 (K4) Baud Rate = 1200 (K3) Baud Rate = 600 (K2) LPN1736 Omni-Directional Laser Scanner Baud Rate = 2400 (K4) Baud Rate = 1200 (K3) Baud Rate = 600 (K2)

  • Page 22: Data Bits

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Data Bits 7 Data Bits (L0) 7 Data Bits (L0) 8 Data Bits (L1) DEFAULT 8 Data Bits (L1) DEFAULT Page 22...

  • Page 23: Stop Bits

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Stop Bits 1Stop Bit (L5) DEFAULT 1 Stop Bit (L5) DEFAULT 2 Stop Bits (L6) 2 Stop Bits (L6) Page 23...
  • Page 24 Manual No. 25-ULPNMU01-01 Parity Even Parity (L3) Odd Parity (L4) Mark No Parity (L2) DEFAULT LPN1736 Omni-Directional Laser Scanner Even Parity (L3) Odd Parity (L4) Mark No Parity (L2) DEFAULT Page 24...

  • Page 25: Chapter 3 Usb Interface

    (+5VDC) is necessary. There is a pig tail adapter with the power supply jack leading to the USB connector Plug the scanner into a USB port on your host computer. The PC must be running Windows 98 (or iMac Rev A) or higher. The computer will sense the presence of the scanner and load any required software driver.

  • Page 26: Programming The Scanner

    This chapter contains information that allows you to easily change certain programmable parameters of the scanner. A specific parameter is set or changed by scanning one or more of the special programming bar codes in this manual. For each parameter, you can choose from a menu of options.
  • Page 27 We recommend that you keep a record of the changes you made to the scanner. At a later time you can reset these changes if needed.

  • Page 28: Programming Symbology Options

    DEFAULT The scanner autodiscriminates among many bar code symbologies. If only one symbology is required, programming the scanner to read only that specific symbology may speed operation and eliminate potential read errors. Enable only all UPC and EAN Codes (J0)
  • Page 29 Manual No. 25-ULPNMU01-01 Enable UPC Only (J1) Enable UPC+2 only (J2) Enable UPC+5 Only (J3) LPN1736 Omni-Directional Laser Scanner Enable UPC only (J1) Enable UPC+2 only (J2) Enable UPC +5 only (J3) Page 29...
  • Page 30 Manual No. 25-ULPNMU01-01 Enable EAN Only (J4) Enable EAN+2 only (J5) Enable EAN+5 Only (J6) LPN1736 Omni-Directional Laser Scanner Enable EAN only (J4) Enable EAN+2 only (J5) Enable EAN+5 only (J6) Page 30...
  • Page 31 Manual No. 25-ULPNMU01-01 Enable Code 39 Only (A2) Enable only Codabar (A3) Enable Only Code 128 (A6) LPN1736 Omni-Directional Laser Scanner Enable only Code 39 (A2) Enable only Codabar (A3) Enable only Code 128 (A6) Page 31...
  • Page 32 Manual No. 25-ULPNMU01-01 Enable Code 93 Only (A5) Enable only MSI/Pless ey (A7) Enable Only Industrial 2of 5 (J7) LPN1736 Omni-Directional Laser Scanner Enable only Code 93 (A5) Enable only MSI Plessey (A7) Enable only Industrial 2of5 (J7) Page 32...
  • Page 33 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Enable only Interleaved 2of5 (J8) Enable Only Interleaved 2of 5 (J8) Enable only IATA (A4 Enable only IATA (A4) Page 33...

  • Page 34: Enabling An Addition Symbology

    Enabling an Additional Symbology These programming bar codes will activate an additional symbology to the symbologies already activated Add UPC (R1) Add UPC+2 (R2) Add UPC+5 (R3) LPN1736 Omni-Directional Laser Scanner Add UPC Add UPC+2 (R2) Add UPC+5 (R3) Page 34...
  • Page 35 Manual No. 25-ULPNMU01-01 Add EAN (R4) These programming bar codes will activate an additional symbology to the symbologies already activated Add EAN+2 (R5) Add EAN+5 (R6) LPN1736 Omni-Directional Laser Scanner Add EAN (R4) Add EAN+2 (R5) Add EAN+5 (R6) Page 35...
  • Page 36 Manual No. 25-ULPNMU01-01 Add Code 39 (B2) Add Codabar (B3) Add Industrial 2of5 (R7) LPN1736 Omni-Directional Laser Scanner Enable Code 39 (B2) Add Codabar (B3) Add Industrial 2of5 (R7) Page 36...
  • Page 37 Manual No. 25-ULPNMU01-01 Add Interleaved 2of 5 (R8) Add Code 128 (B6) Add Code 93 (B5) LPN1736 Omni-Directional Laser Scanner Add Interleaved 2of5 (R8) Add Code 128 (B6) Add Code 93 (B5) Page 37...
  • Page 38 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Add IATA (B4) Add IATA (B4) Add MSI / Plessey (B7) Add MSI / Plessey (B7) Page 38...

  • Page 39: Setting Options

    Manual No. 25-ULPNMU01-01 Setting Options for UPC-A UPC-A Leading zero Transmit Check Digit (E2) UPC-A Leading zero Not transmit Check Digit (E4) LPN1736 Omni-Directional Laser Scanner UPC-A No leading zero Do not transmit Check Digit (E5) Page 39...

  • Page 40: Upc-E

    Manual No. 25-ULPNMU01-01 Setting Options for UPC-E UPC-E no leading zero Transmit Check Digit (E7) UPC-E leading zero Transmit Check Digit (E6) LPN1736 Omni-Directional Laser Scanner UPC-E no leading zero Not transmit Check Digit (E9) Page 40...
  • Page 41 Manual No. 25-ULPNMU01-01 Setting Options for UPC-E . . . continued UPC-E Leading zero Not transmit Check Digit (E8) UPC-E Transmit as UPC-A (6P) LPN1736 Omni-Directional Laser Scanner UPC-E Transmit as is (6Q) Page 41...

  • Page 42: Ean-13 And -8

    Manual No. 25-ULPNMU01-01 Setting Options for EAN-13 and EAN-8 EAN-13 Transmit Check Digit (6K) EAN-8 Transmit Check Digit (6I) LPN1736 Omni-Directional Laser Scanner EAN-13 Not transmit Check Digit (6J) Page 42...
  • Page 43 Manual No. 25-ULPNMU01-01 Setting Options for EAN-13 / EAN-8 . EAN-8 Not transmit Check Digit (6H) Disable ISBN (IB) LPN1736 Omni-Directional Laser Scanner continued Enable ISBN (IA) Page 43...
  • Page 44 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for EAN-13 / EAN-8 . continued Enable ISSN (HO) Disable ISSN (HN) Page 44...

  • Page 45: Code

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for Code 39 Standard Code 39 (D5) DEFAULT Full ASCII Code 39 (D4) Transmit Start/Stop Characters (D0) Page 45...
  • Page 46 Manual No. 25-ULPNMU01-01 Setting Options for Code 39 …. continued Do not transmit Start/Stop Character (D1) Transmit Check Digit (D9) DEFAULT LPN1736 Omni-Directional Laser Scanner Do not transmit Check Digit (D8) Page 46...
  • Page 47 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for Code 39 …. continued Calculate Check Digit (C0) Do not calculate Check Digit (C1) DEFAULT Page 47...

  • Page 48: Codabar

    Manual No. 25-ULPNMU01-01 Setting Options for Codabar Do not transmit Start/Stop Characters (F0) DEFAULT Transmit Start/Stop as abcd/tn*e (F2) LPN1736 Omni-Directional Laser Scanner Transmit Start/Stop as ABCD/tn*E (F1) Page 48...

  • Page 49: Code

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for Codabar ….. continued Transmit Start/Stop as ABCD/ABCD (F3) Transmit Start/Stop as abcd/abcd (F4) Setting Options for Code 128 There are no programmable settings for Code 128 Page 49...
  • Page 50 Manual No. 25-ULPNMU01-01 Setting Options for Code 2of5 Do not calculate Check Digit (G0) DEFAULT Transmit Check Digit (E0) DEFAULT LPN1736 Omni-Directional Laser Scanner Calculate Check Digit (G1) Page 50...
  • Page 51 Manual No. 25-ULPNMU01-01 Setting Options for Code 2of5 …. continued Do not transmit Check Digit (E1) Minimum data: 3 Characters (GF) LPN1736 Omni-Directional Laser Scanner Minimum data: 1 Character (GE) Page 51...
  • Page 52 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for Code 2of5 …. continued Minimum data: 5 Characters (GI) Page 52...

  • Page 53: Msi/Plessey

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for MSI / Plessey Not Check Digit (4A) Calculate Check Digit 1 = Modulo 10 (4B) DEFAULT Calculate Check Digit 2 = Modulo 10/Modulo 10 (4C) Page 53...
  • Page 54 Manual No. 25-ULPNMU01-01 Setting Options for MSI / Plessey …. continued Calculate Check Digit 2 = Modulo 10/Modulo 11 (4D) Transmit Check Digit 1 (4E) LPN1736 Omni-Directional Laser Scanner Do not transmit Check Digit (4G) Page 54...
  • Page 55 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for MSI / Plessey …. continued Transmit Check Digit 1 & 2 (4F) Page 55...

  • Page 56: Iata

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Options for IATA Do not calculate Check Digit (4H) DEFAULT Check S/N only (4I) Check CPN, S/N (4J) Page 56...
  • Page 57 Manual No. 25-ULPNMU01-01 Setting Options for IATA ….. continued Check CPN,Airline and S/N (4K) Do not transmit Check Digit 1 (4M) LPN1736 Omni-Directional Laser Scanner Transmit Check Digit (4L) DEFAULT Page 57...

  • Page 58: Universal Programming Options

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Chapter 6 Universal Programming Options These programming commands apply to all interfaces and symbologies Redundant Decoding No Redundacy (X0) Read 2 times (X1) DEFAULT Page 58...
  • Page 59 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Redundant Decoding ….. Continued Read 3 times (X2) Read 4 times (X3) Page 59...

  • Page 60: Read Mode

    Manual No. 25-ULPNMU01-01 Read Mode Single Read (S0) Continuous Read (S2) LPN1736 Omni-Directional Laser Scanner Multiple Read (S1) DEFAULT Page 60...

  • Page 61: Beeper Options

    Manual No. 25-ULPNMU01-01 Beeper Options Disable Beeper (W0) High - Low Beeper (W2) LPN1736 Omni-Directional Laser Scanner Single Tone Beeper (W1) Page 61...
  • Page 62 Manual No. 25-ULPNMU01-01 Beeper Options …… continued Low - High Beeper (W3) Beeper Duration: 100ms (W4) LPN1736 Omni-Directional Laser Scanner Beeper Duration: 50ms (W7) Page 62...
  • Page 63 Manual No. 25-ULPNMU01-01 Beeper Options …… continued Beeper Duration: 400ms (W6) Loudness: Loud (T1) LPN1736 Omni-Directional Laser Scanner Loudness: Maximum (T0) DEFAULT Page 63...
  • Page 64 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Beeper Options …… continued Loudness: Normal (T2) Loudness: Minimum (T3) Page 64...
  • Page 65 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Beeper Options …… continued Beeper before transmission (VY) Beeper after transmission (VZ) DEFAULT Page 65...

  • Page 66: Prefix Options

    2. Select the symbologies to which you wish to add the Prefix. 3. Scan the Direct Input Characters that you want in the Prefix 4. Scan the “Start/Stop Programming Mode” bar code Clear All Prefixes (MG) LPN1736 Omni-Directional Laser Scanner Page 66...
  • Page 67 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Prefix Options …… continued Add Prefix to All Symbologies (RY) Add Prefix to UPC-A (N1) Add Prefix to UPC-A plus all add-ons (M0) Page 67...
  • Page 68 Manual No. 25-ULPNMU01-01 Prefix Options …… continued Add Prefix to UPC-E (N2) Add Prefix to EAN-13 (N3) LPN1736 Omni-Directional Laser Scanner Add Prefix to UPC-E plus all Add-Ons (M1) Page 68...
  • Page 69 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Prefix Options …… continued Add Prefix to EAN-13 plus Add-Ons (M2) Add Prefix to EAN-8 (N4) Add Prefix to EAN-8 plus Add-Ons (M3) Page 69...
  • Page 70 Manual No. 25-ULPNMU01-01 Prefix Options …… continued Add Prefix to Code 39 (M4) Add Prefix to Industrial 2of5 (M6) LPN1736 Omni-Directional Laser Scanner Add Prefix Codabar (M5) Page 70...
  • Page 71 Manual No. 25-ULPNMU01-01 Prefix Options …… continued Add Prefix to Interleaved 2of5 (M7) Add Prefix to Code 93 (M8) LPN1736 Omni-Directional Laser Scanner Add Prefix to IATA (I8) Page 71...
  • Page 72 Manual No. 25-ULPNMU01-01 Prefix Options …… continued Add Prefix to Code 128 (M9) Add Prefix to Telepen (L8) LPN1736 Omni-Directional Laser Scanner Add Prefix to MSI/Plessey (N0) Page 72...

  • Page 73: Suffix Options

    6. Select the symbologies to which you wish to add the Suffix. 7. Scan the Direct Input Characters that you want in the Suffix 8. Scan the “Start/Stop Programming Mode” bar code Clear All Suffixes (PR) LPN1736 Omni-Directional Laser Scanner Page 73...
  • Page 74 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Sufffix Options …… continued Add Suffix to All Symbologies (RZ) Add Sufffix to UPC-A (N6) Add Suffix to UPC-A plus all add-ons (O0) Page 74...
  • Page 75 Manual No. 25-ULPNMU01-01 Suffix Options …… continued Add Suffix to UPC-E (N7) Add Suffix to EAN-13 (N8) LPN1736 Omni-Directional Laser Scanner Add Suffix to UPC-E plus all Add-Ons (O1) Page 75...
  • Page 76 Manual No. 25-ULPNMU01-01 Suffix Options …… continued Add Suffix to EAN-13 plus Add-Ons (O2) Add Suffix to EAN-8 plus Add-Ons (O3) LPN1736 Omni-Directional Laser Scanner Add Suffix to EAN-8 (N9) Page 76...
  • Page 77 Manual No. 25-ULPNMU01-01 Suffix Options …… continued Add Suffix to Code 39 (O4) Add Suffix to Industrial 2of5 (O6) LPN1736 Omni-Directional Laser Scanner Add Suffix to Codabar (O5) Page 77...
  • Page 78 Manual No. 25-ULPNMU01-01 Suffix Options …… continued Add Suffix to Interleaved 2of5 (O7) Add Suffix to Code 93 (O8) LPN1736 Omni-Directional Laser Scanner Add Suffix to IATA (I9) Page 78...
  • Page 79 Manual No. 25-ULPNMU01-01 Suffix Options …… continued Add Suffix to Code 128 (O9) Add Suffix to Telepen (L9) LPN1736 Omni-Directional Laser Scanner Add Suffix to MSI/Plessey (N5) Page 79...

  • Page 80: Direct Input: Keyboard Keys For Prefix & Suffix

    Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys F1 Key (8J) F3 Key (8L) LPN1736 Omni-Directional Laser Scanner F2 Key (8K) Page 80...
  • Page 81 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued F4 Key (8M) F6 Key (8O) LPN1736 Omni-Directional Laser Scanner F5 Key (8N) Page 81...
  • Page 82 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued F7 Key (8P ) F9 Key (8R) LPN1736 Omni-Directional Laser Scanner F8 Key (8Q) Page 82...
  • Page 83 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued F10 Key (8S) F12 Key (8U) LPN1736 Omni-Directional Laser Scanner F11 Key (8T) Page 83...
  • Page 84 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued Backspace (9X) Carriage Return (7I) LPN1736 Omni-Directional Laser Scanner (7H) Page 84...
  • Page 85 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued Enter (numeric pad) (7Q) Enter make and break (alpha pad) (7S) LPN1736 Omni-Directional Laser Scanner Enter make (alpha pad) (7R) Page 85...
  • Page 86 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued (7J) Arrow up (7L) LPN1736 Omni-Directional Laser Scanner Arrow down (7K) Page 86...
  • Page 87 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued Arrow right (7M) <DEL> (7T) LPN1736 Omni-Directional Laser Scanner Arrow left (7N) Page 87...
  • Page 88 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued <INSERT> (VQ) <END> (VS) LPN1736 Omni-Directional Laser Scanner <HOME> (VR) Page 88...
  • Page 89 Manual No. 25-ULPNMU01-01 Direct Input -- Keyboard Keys …… continued Page up (7O) Left <Control> (7W) LPN1736 Omni-Directional Laser Scanner Page down (7P) Page 89...
  • Page 90 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Keyboard Keys …… continued Left <Alt> (7Y) Right <Shift> (7V) Right <Control> (7X) Page 90...
  • Page 91 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Keyboard Keys …… continued Right <Alt> (7Z) CAPSLOCK (9S) Page 91...
  • Page 92 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys Space bar (5A) (5B) “ (5C) Page 92...
  • Page 93 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (5D ) (5E) (5F) Page 93...
  • Page 94 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued & (5G) ‘ (5H) (5I) Page 94...
  • Page 95 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (5J ) (5K) (5L) Page 95...
  • Page 96 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (5M) (5N) (5O) Page 96...
  • Page 97 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (5P) (6A) (6B) Page 97...
  • Page 98 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued < (6C) (6D) > (6E) Page 98...
  • Page 99 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (6F) (6G) (7A) Page 99...
  • Page 100 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (7B) (7C) (7D) Page 100...
  • Page 101 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (7E) (7F) (9T) Page 101...
  • Page 102 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Character Keys …… continued (9U) (9V) (9W) Page 102...

  • Page 103: Direct Input: Numeric Characters

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Numeric Characters (Q0) (Q1) (Q2) Page 103...
  • Page 104 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Numeric Characters …continued (Q3) (Q4) (Q5) Page 104...
  • Page 105 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Numeric Characters … continued (Q6) (Q7) (Q8) Page 105...

  • Page 106: Direct Input: Alpha Characters

    Manual No. 25-ULPNMU01-01 Direct Input -- Numeric Characters … continued (Q9) Direct Input -- Alpha Characters (0B) LPN1736 Omni-Directional Laser Scanner (0A) Page 106...
  • Page 107 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0C) (0D) (0E) Page 107...
  • Page 108 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0F) (0G) (0H) Page 108...
  • Page 109 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0I) (0J) (0K) Page 109...
  • Page 110 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0L) (0M) (0N) Page 110...
  • Page 111 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0O) (0P) (0Q) Page 111...
  • Page 112 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0R) (0S) (0T) Page 112...
  • Page 113 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0U) (0V) (0W) Page 113...
  • Page 114 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued (0X) (0Y) (0Z) Page 114...
  • Page 115 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($A) ($B) ($C) Page 115...
  • Page 116 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($D) ($E) ($F) Page 116...
  • Page 117 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($G) ($H) ($I) Page 117...
  • Page 118 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($J) ($K) ($L) Page 118...
  • Page 119 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($M) ($N) ($O) Page 119...
  • Page 120 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($P) ($Q) ($R) Page 120...
  • Page 121 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($S) ($T) ($U) Page 121...
  • Page 122 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($V) ($W) ($X) Page 122...
  • Page 123 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Alpha Characters …… continued ($Y) ($Z) Page 123...

  • Page 124: Direct Input: Control Characters

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ^@ (NULL) (9G) ^A(SOH) (1A) ^B(STX) (1B) Page 124...
  • Page 125 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^C(ETX) (1C) ^D(EOT) (1D) ^E(ENQ) (1E) Page 125...
  • Page 126 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^F(ACK) (1F) ^G(BEL) (1G) ^H(BS) (1H) Page 126...
  • Page 127 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^I(HT) (1I) ^J(LF) (1J) ^K(VT) (1K) Page 127...
  • Page 128 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^L(FF) (1L) ^M(CRF) (1M) ^N(SO) (1N) Page 128...
  • Page 129 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^O(SI) (1O) ^P(DLE) (1P) ^Q(DC1) (1Q) Page 129...
  • Page 130 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^R(DC2) (1R) ^S(DC3) (1S) ^T(DC4) (1T) Page 130...
  • Page 131 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^U(NAK) (1U) ^V(SYN) (1V) ^W(ETB) (1W) Page 131...
  • Page 132 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^X(CAN) (1X) ^Y(EM) (1Y) ^Z(SUB) (1Z) Page 132...
  • Page 133 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^[(ESC) (9A) ^\(FS) (9B) ^](GS) (9C) Page 133...
  • Page 134 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Control Characters ...continued ^^(RS) (9D) ^_ (US) (9E) DEL (ASCII 127) (9F) Page 134...

  • Page 135: Direct Input -- Code Id / Length

    Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Direct Input -- Code ID / Length Code Identification ($2) Code Length ($3) Page 135...

  • Page 136: Sleep Mode

    Manual No. 25-ULPNMU01-01 Sleep Mode The default setting of the LPN 1736 the laser diode and motor are “on” whenever power is applied to the scanner. The scanner can be programmed to turn off the laser and the motor after a period of time with no scanning activity (no bar code presented for scanning).
  • Page 137 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Setting Sleep Period to One Hour Enable Trigger (S8) Readtime: Indefinite (YM) Trigger Sensitivity = Avg (+I) Page 137...
  • Page 138 Manual No. 25-ULPNMU01-01 Setting Sleep Period to One Hour…continued Disable Motor When Idle (4Z) Direct Input: 3 (Q3) LPN1736 Omni-Directional Laser Scanner Set Auto Shut Off Time (BBB) Page 138...
  • Page 139 Manual No. 25-ULPNMU01-01 Setting Sleep Period to One Hour…continued Direct Input: 6 (Q6) Direct Input: 0 (Q0) LPN1736 Omni-Directional Laser Scanner Direct Input: 0 (Q0) Page 139...
  • Page 140 The auto sensor can be adjusted to compensate for dark colored work surface and a white or light color area surrounding the bar code. Auto Sensor = Dark/Bright (+G) LPN1736 Omni-Directional Laser Scanner Auto Trigger = Bright/Dark (+H) Page 140...
  • Page 141 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Motor Speed in Sleep Mode In the default setting, when the scanning is in the Sleep Mode, the motor is Off. To provide a faster “wake up” when an object is sensed, the motor can be set to run at normal speed or at half speed.

  • Page 142: Start / Stop Programming Bar Code

    Appendix A Start / Stop Programming Bar Code Opticon scanners are preprogrammed at the factory with default settings representing the settings most commonly used by our customers. In most applications, the scanner will work right out of the box without the need for additional programming.
  • Page 143 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Appendix B Scanning Template for Programming Cut and Remove this section to create a window Page 143...

  • Page 144: Appendix C Default Settings

    Wedge Intercharacter Delay RS232 Interface Baud Rate No. of Data Bits No. of Stop Bits Flow Control Handshaking Redundant Reads before Transmit Read Twice LPN1736 Omni-Directional Laser Scanner Enabled Enabled Disable Enabled Enabled Enabled Disable Disable Enabled Enabled Enabled Enabled...
  • Page 145 In the unlikely situation that these default settings are lost or changed, they can be re-established. Scanning the following programming bar codes in sequence will activate the required settings. Start/Stop Programming Mode (ZZ) Transmit UPC E as UPC A (6P) LPN1736 Omni-Directional Laser Scanner Default (U2) Page 145...
  • Page 146 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner Settings for Ruby VeriFone – continued 1200 Baud (K3) No Handshaking (P0) Add Prefix for UPC A (N1) Page 146...
  • Page 147 Manual No. 25-ULPNMU01-01 Settings for Ruby VeriFone – continued Prefix = A (0A) Prefix = A (0A) LPN1736 Omni-Directional Laser Scanner Add Prefix for EAN 8 (N4) Page 147...
  • Page 148 Manual No. 25-ULPNMU01-01 Settings for Ruby VeriFone – continued Set Prefix for EAN 13 (N3) Start/Stop Programming Mode (ZZ) LPN1736 Omni-Directional Laser Scanner Prefix for EAN 13 = A (0A) Page 148...
  • Page 149 Manual No. 25-ULPNMU01-01 LPN1736 Omni-Directional Laser Scanner LPN1736 Manual Update- September 13, 2005 Page 149...

Table of Contents
