Connectors

9.3.1.
a) DOS/V Host Connector

Figure 20: DOS/V host connector

Contact Number
1
2
3
4
5
6
b) DOS/V Keyboard Connector

Figure 21: DOS/V keyboard connector

Contact Number
1
2
3
4
5
6
Do not use the keyboard while the scanner is transmitting the data to the host.
Doing so may cause failure in data transactions.
4
6
5
3
Signal Name
CPU_DATA
NC
GND
VCC
CPU_CLK
NC
3
5
6
4
Signal Name
KEY_DATA
NC
GND
VCC
KEY_CLK
NC
24
Opticon
Specifications Manual
2
1
1
2
C37
