TECHNICAL SPECIFICATION

Switchable channels
Frequency bandwidth
Switching bandwidth
Temperature range
RF output power
Max RF output power
"A" / "B" antenna output
RF impedance
Spurious emissions
Modulation
Peak deviation
MPX Pilot tone
Tone squelch
Frequency response
Analogue audio input
Connector type
Max. input level
Pin Assignments
Digital audio input
Connection
Monitor output
Connector type
Monitor output level
Monitor out impedance
Compander
Display
Configuration/monitor
interfaces
Power supply
Dimensions
: 2400 allocated by 40 groups of 60 channels quickly selectable with dedicated buttons
: 470-800 MHz
: 330 MHz tuneable in 5 kHz steps
: -10 ÷ +55 °C
: Selectable: 10,20,50,100,200 mW (ERP) for MTK952-0W2
: MTK952-W05: 50mW
MTK952-0W2: 200mW
MTK952-2W0: 2Watt
[NOTE] RF power can be limited on frequency base accordingly to specific country
restrictions (software based)
: with BNC type female connectors
: 50 Ω
: < 2 nW (in the transmitter bandwidth)
: FM, MPX Stereo or mono, selectable with dedicated menu
: ±56 kHz for mono, ±48 kHz for stereo (preset mode)
NOTE: custom setting can set peak deviation from 2kHz to 100kHz
: 19kHz
: 32.789Hz (for Wisycom wireless microphone, i.e. ENR/ENC)
131,8 (for Wisycom intercom, i.e. NR)
NOTE: custom setting can change the Tone squelch (30-260Hz and 28K-34KHz)
: 20÷20kHz (mono)
30÷15kHz (stereo)
NOTE: custom setting can change audio bandwidth (3/4/12/15/20kHz)
: XLR-3 / 1/4" (6,3mm) jack combo socket, electronically balanced
: +18dBu
: XLR: 1=ground 2=hot 3 =cold
6.35mm (1/4") TRS: Tip=hot Ring=cold Sleeve=ground
: AES3 on XLR-3M (32kHz ÷108 kHz)
: 6.35mm (1/4") jack socket, balanced
: max 240mW @ 150 ohm
: 100 ohm for auricle
: ENR (Wisycom Extended-NR), with independent Attack- and Recovery-time, noise
optimized
ENC (Wisycom Extended-NC), with independent Attack- and Recovery-time, voice
optimized & with reduced pre-emphasys
NONE-d50, no compander, pre-emphasis 50 µs
NR, to work with Wisycom Intercom system
Other compander on request
: 64 x 256 OLED (yellow)
: 10/100 Base TX Ethernet port on RJ45 connector
: 90 - 264 V AC, 50/60 Hz
10 – 16 VDC, Max 6A (option DCI952)
: 19"/1U 483 x 407 x 43,8 mm (WxDxH) with brackets
