- Page 1 MTK982 User Manual Dual Transmitter Mono - Stereo - Intercom Modulation rev.07 (ref. FW 2.1.0) Date: 05 September 2024...
- Page 2 MTK982 User Manual rev.07 AFETY INSTRUCTION • Read these safety instructions and the manual first. • Follow all instructions and information provided. • Do not lose this manual. • Do not use this apparatus in the rain or near water.
- Page 3 9 to 12 for analog audio sources). The cascade configuration allows the same analog audio input to be used for multiple transmitters. Power on the MTK982 Switch off the RF output: Enter in the AUDIO menu and...
- Page 4 ANEL ONTROL AND UNCTIONS MTK982 allows an easy and quick configuration using buttons, push knobs and displays. The front panel is functionally divided in the following section: A – LOCK and IrDA Lock button allows to lock editing of one of both the transmitters.
- Page 5 MTK982 User Manual rev.07 ANEL ❶❷❸ ❹ ❺ ❻ ❼ ❾ ❿ ⓫ ⓬ ❽ ⓭ ⓮ ⓯ ❶ Ground point To connect the rack to ground ❷ AC Power Plug AC mains power input, IEC Connector 90-264 Vac ❸...
- Page 6 RANSMITTER MENU AND RONT ANEL MTK982 info screen Switch on the MTK982 and by pushing one of rotatory knobs (at the right of the display) all the basic information are displayed: Display of TRANSMITTER 1 Display of TRANSMITTER 2 On the display of TX2, it is possible to check the max level of power transmitted of the MK952, the ❶...
- Page 7 The ON/OFF button is very straightforward. It quickly turns your transmitter on and off, providing easy and efficient operation. For the MTK982, there is an option to automatically turn on the transmitter at startup. To enable this option, activate 'Advanced Settings', then in the 'TX Power' menu, select 'TX ON at startup'.
- Page 8 MTK982 User Manual rev.07 ENU TREE MTK982 offers 2 levels of access to the menu: • BASIC: allows access to the main configuration parameters for Stereo/IFB application. • ADVANCED: Allows access to additional parameters, including: Multiple selectable receivers Editable power settings parameters...
- Page 9 MTK982 User Manual rev.07 BASIC MENU...
- Page 10 MTK982 User Manual rev.07 ADVANCED MENU...
- Page 11 MTK982 User Manual rev.07 Receiver The receiver menu allows you to configure the audio treatment at the transmitter. By rotating the knob, you can switch between the available receivers. Check the external label of the receiver to identify the model you are using and set the receiver type according to the table below:...
- Page 12 When EXT. ATT. is enabled and the transmitter is connected to a Wisycom smart combiner (CSI16T2, CSI16T, CSA121T), the transmitter automatically adjusts the output power to compensate for the loss due to the passive combiner. Therefore, the RF power configured on the MTK982 will be present at the end of the combiner.
- Page 13 This menu allows you to decide whether to turn ON or OFF the RF power of the transmitter while the MTK982 is powering on. If set to No: While the MTK982 is powering on, the RF output remains muted. The Status Screen on the display shows "OFF".
- Page 14 MTK982 User Manual rev.07 Equalizer This menu allows you to adjust the gain between frequency components (bass, mid, and treble) within the audio signal. There are four cascading windows: Bass window: Allows you to change the gain and frequency of low frequencies.
- Page 15 If the synchronization is successful, the display of the devices shows number of channel and group or SYNC channel according to the frequency plan memorized on the Wisycom product:...
- Page 16 Status screen SYNC RX parameters The SYNC RX parameters is useful to tune the channels of the MTK982 on the same frequency of the receiver via the IR interface, and quickly choose which other parameters you want to be the same with your RX.
- Page 17 MTK982 User Manual rev.07 Ex. FREQUENCY SCAN Display of Transmitter1 Display of Transmitter2 Ex: GROUP SCAN Display of Transmitter1 Display of Transmitter2 ➢ Use the membrane buttons on display2 to set the frequency to TX1 – TX2 NOTE: The results of the scan are saved on the volatile memory of the transmitter: After the switch off of the transmitter the data are lost.
- Page 18 MTK982 User Manual rev.07 Alarm List When an alarm occurs, the MTK982 can do one or more of the following acts: A. Show a message on the display B. Turn on the yellow or red alarm led C. Insert the alarm on the alarm list in the MAIN>Options>Info>Alarms menu The alarm can be related to a specific transmitter (TX1 or TX2) or general.
- Page 19 0x02 or 0x03 on the alarm list) > 60°C - switch off the MTK982 for cooling and check the location temperature - clean the ventilation grids Fan #1 doesn't work The fan on the left (#1) doesn’t...
- Page 20 MTK982 User Manual rev.07 Configurations MTK982 - <Country> - <PowerSupply> Country Power Profile: Europe, 470-760 MHz (max power 50mW) Europe, 470-760 MHz (max power 2Watt) USA, 470-663 MHz (max power 250mW) Canada, 470-663 MHz (max power 250mW) Japan, 470-714 MHz (max power 10mW)
- Page 21 Japan 50mW 217-241287 MTK982-JP3 1240-1260 Japan MTK982-KR KC: R-C-WIY-MTK982 250mW 470-698 Korea Before putting the device into operation, please observe the respective country-specific regulations! MTK982-EUX is not an SRD device, thus it requires specific authorization by your local frequency authority!
- Page 22 MTK982 User Manual rev.07 MANUFACTURER DECLARATIONS In compliance with the following requirements • RoHS Directive (2002/95/EC) • WEEE Directive (2002/96/EC) Please dispose of the diversity transmitter at the end of its operational lifetime by taking it to your local collection point or recycling center for such equipment...
- Page 23 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Les antennes ne sont pas fournies avec cet appareil. Cet émetteur radio (IC : 11967A-MTK982) a été approuvé par Industrie Canada pour fonctionner avec l'antenne ayant un gain maximum de 3 dBi. Antennes ayant un gain supérieur sont strictement interdites pour une utilisation avec ce produit.
- Page 24 -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications made to this equipment not expressly approved by Wisycom srl may void the FCC authorization to operate this equipment.
- Page 25 MTK982 User Manual rev.07 Wisycom srl Via Tiepolo, 7/E 35019 Tombolo (PD) – Italy E-mail: sales@wisycom.com www.wisycom.com...
