TECHNICAL SPECIFICATION

Frequency ranges
Switchable channels
Switching-window
Frequencies
RF Power
Max RF output power
Antenna connector
Auxiliary RF connector
RF impedance
Modulation
Peak deviation
MPX Pilot tone
Tone squelch
Spurious emissions
Noise Reduction system
AF bandwidth
Audio input connector
Audio input level
Pin Assignments
Digital output
Monitor output
Monitor output level
Monitor out impedance
Managing interface
Display
Power supply
DC options
Temperature range
Dimensions
Weight
From 430 to 1260 MHz, depends on the country (see Configurations)
2400 managed in 40 groups ofr 60 frequencies completely user customizable
330 MHz tuneable
5 kHz steps
switchable typ. 10,20,30,50,75,100,150,200,250,400,500,750,1000,1200,1500,2000 mW (ERP)
2 Watt, RF power can be limited on frequency base accordingly to specific country restrictions
2 x BNC type female
2 x SMA type female
50 Ω
FM, MPX Stereo or mono, selectable with dedicated menu
±56 kHz for mono wideband, ±35 kHz for mono narrowband, ±48 kHz for stereo
(preset mode)
19kHz
32.789Hz (for Wisycom wireless microphone, i.e. ENR/ENC)
131,8 (for Wisycom intercom, i.e. NR)
NOTE: custom setting can change the Tone squelch (30-260Hz and 18-38KHz)
< 2 nW
ENS , ENC, ENR, NONE-d50, no compander, pre-emphasis 50 μs
NR, to work with Wisycom Intercom system
Other compander on request
20÷20kHz (mono)
30÷15kHz (stereo)
NOTE: custom setting can change audio bandwidth (3/4/12/15/20kHz)
XLR-3 / 1/4" (6,3mm) jack combo socket, electronically balanced
+18dBu
XLR: 1=ground 2=hot 3 =cold
6.35mm (1/4") TRS: Tip=hot Ring=cold Sleeve=ground
AES3 on XLR-3M (32kHz ÷108 kHz)
6.35mm (1/4") jack socket, balanced
120+120mW@24Ω , 80+80mW@150Ω
25Ω for auricle
10/100 Base TX Ethernet port on RJ45 connector
64 x 256 OLED (white)
90 - 264 V AC, 47/63 Hz
10-28 Vdc, 6A max
-10 ÷ +55 °C
19"/1U 43,8 x 483 x 349 mm (HxWxD) with brackets
4 kg approx.
