WisyCom MTB40 User Manual

Wideband plug-on transmitter
Hide thumbs Also See for MTB40:
Table of Contents

Advertisement

Quick Links

Download this manual
MTB40 User Manual
Wideband Plug-on
Transmitter
SN: ________________
Rev.02 (rif. FW 1.11.0E)
Date: 10 September 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTB40 and is the answer not in the manual?

Questions and answers

Related Manuals for WisyCom MTB40

Summary of Contents for WisyCom MTB40

  • Page 1 MTB40 User Manual Wideband Plug-on Transmitter SN: ________________ Rev.02 (rif. FW 1.11.0E) Date: 10 September 2013...

  • Page 2: Safety Instruction

    MTB40 is an extremely small and light plug-on transmitter especially designed for professional wireless microphone applications. Very easy and quick to use thanks to OLED display, MTB40 benefit also of the latest Wisycom RF technology along with an enhanced robustness against noise and inter-modulation.

  • Page 3: Led Indication

    Modulation peek (if activated): red. ATTERIES MTB40 is working with 2 AA alkaline or NiMH batteries (select correct type on setup controls). Battery status can be checked on internal OLED display or looking to LED status on front. BATTERY SUBSTITUTION ...

  • Page 4: Power Up/Down

    MTB40 User Manual Rev.02 POWER UP/DOWN Buttons Mode To… Status display - power off the device - power off the RF transmission - exit from the operating menu Operating menu Cancel the entry and return to the standard display Setting mode...

  • Page 5: Display Menu

    MTB40 User Manual Rev.02 DISPLAY MENU Setup menu are accessed in sequence: STATUS Current: PRESET Load from: FACTORY/USER/PRESET1/2/3/4/5/6/7/8 Save to: USER 00-59 00-39 TUNING 1: 470.000÷640.000 Freq 2: 566.000÷798.000 Name AF In Gain -40÷40 dsB (1dB step) AUDIO HPass Filter...
  • Page 6 <STATUS> menu This is the first menu displayed after power up. Major info are displayed: - Current channel/group or the receiver name if the MTB40 is already synchronized with a receiver - Current frequency (i.e. 566.000 MHz) - Mic gain (i.e. AF: -04 dB) and high pass filter (i.e. HP: Flat Hz) - “RF 50”...
  • Page 7 MTB40 User Manual Rev.02 <TUNING> menu This menu can be entered by pushing In this menu channel/group and frequencies can be setup. Sync group is a quick self-settable channel synchronized by receiver. Use the selector ( ) to change values and <SEL> to confirm.
  • Page 8 NOTE: while in this menu display is not automatically turned off. <LOCK> menu This menu can be entered by pushing Long pressing (2 sec.) selector button (SEL) it locks MTB40 in transmission mode. To unlock, long pressing (2 sec.) selector button again.
  • Page 9 MTB40 User Manual Rev.02 <CH/GAIN> Quick menu Push CH/GAIN button (❽) to change quickly the values of CH or GAIN. Use the selector ( to change the values of CH or GAIN and <SEL> to confirm. These menus display larger characters to easily operate channel/gain settings.

  • Page 10: Wisycom Ir Programmer ( Ver . 1.3.2.0 And Above )

    It is necessary to:  install Wisycom IR Programmer (version 1.3.2.0 or above) WARNING: If it is the first installation and Wisycom USB driver has not already installed in the PC, install the USB driver (run C:\Program Files (x86)\Wisycom\MTP&MTH Infrared Programmer (TX)\Drivers\ DriverInstaller.exe) ...

  • Page 11: Interface And Device Panel

    OLED display). Each parameter can be locked clicking the related lock button, so the set value cannot be changed next using the OLED display. In the audio panel it’s also possible to change the unit of measurements of the gain choosing between dB (gain in dB of MTB40 amplifiers) or in dBµ peak.

  • Page 12: Tuning Frequencies Panel

    MTB40 User Manual Rev.02 TUNING FREQUENCIES PANEL In Tuning Frequencies panel, the user can select a frequencies group (0÷39) and for each one execute the following operations: modify the Group’s Name lock and/or hidden the group for each channel (0 ÷59) of the selected group: change the frequency value and the...
  • Page 13 MTB40 User Manual Rev.02 Using the LOAD/SAVE button, at the bottom of the panel, it is possible to load/save the frequencies for the selected group from/to a .wdf file. To save the frequencies of all the groups click to the related button above. The legacy option save the channels without the hidden/lock...

  • Page 14: Presets Panel

    Using a file menu at the top left of the panel it is possible to load/save all the configuration values of the device to/from a .wcf file (Wisycom Configuration File). Save a .wcf file With an infrared device correctly connected, select File->Save User Configuration and select the destination file.

  • Page 15: Technical Specifications

    FM, with 50 µs pre-emphasis Modulation ±40 kHz (Peak deviation = ±56 kHz) Nominal deviation MTB40 transmits also a digitally modulated sub-carrier, suitable for: Telemetry ▪tone-squelch operating ▪ remote battery monitoring ▪ optional PTT (Push to talk) operation feature...
  • Page 16 MTB40 User Manual Rev.02 Mechanical Drawing...

  • Page 17: Declaration Of Conformity

    MTB40 User Manual Rev.02 DECLARATION OF CONFORMITY...
  • Page 18 MTB40 User Manual Rev.02 ENVIRONMENTAL INFORMATION Applicable in the European Union and other European countries with separate collection systems Disposal of Old Electrical & Electronic Equipment (2002/96/EC) This symbol indicates that this product shall not be treated as household waste.
  • Page 19 MTB40 User Manual Rev.02...
  • Page 20 WISYCOM S.r.l.   Via Spin 156 I-36060 Romano d’Ezzelino Italy  Tel. +39 -0424 -382605 Fax +39 - 0424 - 382733  www.wisycom.com e-mail: sales@wisycom.com...
