MTP61 multi-band miniature transmitter

TECHNICAL SPECIFICATION

Frequency range
Switchable channels
Switching-window
Frequencies
Frequency error
RF Power
Antenna connector
Modulation
Nominal deviation
Peak deviation
Spurious emissions
Telemetry feature
Noise Reduction system
AF bandwidth
Distortion
SND/D ratio (Analogue)
Audio input connector
Audio input level
Max input level
Storage media
Time code
Bit rate
Sampling rate
Managing interface
LED
Battery level indication
PTT function
Display
Power supply
Power consumption
Battery life
Temperature range
Dimensions
Weight
from 470 to 1260 Mhz, depends on the country (see Configurations)
2400 managed in 40 groups ofr 60 frequencies completely user programmable
Up to 362 MHz, depending on band (see Configurations)
Quartz PLL frequency synthesizer circuit (5 kHz step)
±2.5 ppm, in the rated temperature range
10mW/ L10 W/ 20 mW/ L20 mW / 50 mW /100 mW
SSMA
Wideband and Narrow-band with DSP based digital signal processing
±40 kHz Wideband / ±25 kHz Narrowband
±56 kHz Wideband / ±35 kHz Narrowband
< 2 nW
TX transmits also a digitally modulated sub-carrier, suitable for:
• tone-squelch operating
• remote battery monitoring
• optional PTT (push to talk) operation
ENS - Wisycom ultra-high permorfmance compander
Audio frequency response (dBa):
• 45 Hz ÷ 17 KHz (3dB) in NarrowBand mode (NB)
• 45 Hz ÷ 20 KHz (3dB) in WideBand mode (WB)
< 0.3 % (0.15 % typ.)
typ. 115 dB (A)rms with 40 kHz deviation; typ. 121 dB (A)rms with 56 kHz deviation Wideband
typ. 115 dB (A)rms with 25 kHz deviation; typ. 121 dB (A)rms with 35 kHz deviation Narrowband
LEMO 3pin
from -40 dBu (12mVrms) to 6 dBu (1.55 Vrms) adjustable in 1 dB steps
+6 dBu (1.55 Vrms) at clipping
internal 64 GB micro SD memory card (industrial grade heavy duty)
Linear Timecode decoding
24 bit / 32 bit
48 kHz
Bluetooth 5.2 low energy long range,
proprietary waterproof magnetic connector 5 pin (USB HS +power +LTC)
3 RGB LEDs (red, green and blue) for audio, RF, battery status and battery charger
percentage or minute/second
Pin 3 of AF connector can be controlled via an externall PTT button
High contrast OLED white display (128 x 64 pixels)
Cameron Sino Lithium-ion battery Model CS-BCE10 Part No. CGA-S008E (3.7V, 1050 mAh)
250mA@ 3V average (display off, 100mW power)
approx. 8 hours @ 10mW
-10 ÷ +55 °C
66,8mm x 47mm x 17mm (HxWxD) without clip
Approx. 72 g. without battery, 94 g. with battery
