MTK952 User Manual
Synchronization
The SYNC function is useful to tune a transmitter on the same frequency of the receiver via the IR
interface. Before starting the sync function tune the receiver on desired channel, manually or using
the SCAN utility. After this, enable the IR interface on the receiver. Now press the Sync button
and "START" on the transmitter that you want to sync to start the SYNC function.
Keep the IR window of the transmitter in front of the IR window of the receiver and, as soon as
the connection is done, the receiver will send to the transmitter all the information needed
(frequency, channel, group and receiver name).
START TX1
START TX2
If the operation is not possible, (i.e. the frequency range of the transmitter is not compatible with
the frequency of the receiver), the display will show an error message.
After synchronization, the transmitter show the name of the receiver (ex. SINGER_1)
CASE A: if frequency, channel and group are the same in the two devices, channel and group are
also displayed (ex: CH00: 566.000, GR39: Unlock)
CASE B: If frequency, channel & group of the transmitter are different from those of the receiver,
the transmitter shows only the frequency after the word SYNC. (ex: SYNC: 620.000)
Message displayed after the synchronization
Status screen
14
