Specifications

Ethernet Connections
• SFP 1000 Base-X
• SFP 100 Base –FX
• SFP 10/100/1000 Copper (SGMII)
• 10/100/1000 BaseT (Fixed Copper ports)
• Auto Negotiation
• Auto-Cross
• Flow Control
• Up to 10,240 MTU
• Full Line-Rate Forwarding
Power
DC terminal
DC jack
Double-USB Power
Cable
AC wall adapter
Operating Temperature
-40°F to +185°F (-40°C to +85°C) DC configuration
+14°F to +122°F (-10°C to +50°C) with AC wall adapter
Storage Temperature
-67°F to +257°F (-55°C to +125° C)
Humidity
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
0.79"H x 3.82"W x 3.82"D (2cm H x 9.7cm W x 9.7cm D))
Current Draw
1.5A @ room temperature with data and copper SFPs
1.1A @ room temperature with fiber SFPs
48 VDC, Telco (42.5 to 56.5 VDC with 10mSec transients to
75 VDC)
5 VDC - 24 VDC
Spec 500mA
Note that the laptop or PC USB ports must be 2.0 or greater
to provide sufficient power to the unit.
Input: 100 to 240 ±10% VAC
Output: 5 VDC, 2A max.
