DIP Switch Selectable Mode Configuration

The IE-MultiWay can be configured in one of the following ways via DIP Switch
settings (see page 7):
Configuration
Method
4-Port Switch In this mode, the unit acts as a standard 4-port MAC-layer switch.
(default)
Dual In this mode, the unit functions as two independent (SFP to TX)
Converter media converters and traffic never passes between the two
mode converters.
1+1 SFP
In this mode, the "SFP A" port (fiber or copper) is connected
Protection
through the switch to the drop ports as the main link. The "SFP B"
Non-Revertive
port (fiber or copper) is active into the MAC switch, but no
mode
connection inside the switch is made; in this way, the "SFP B" line
is held as the standby line. The "SFP B" line is held in the LINK
state for testing and line verification, but does not actively carry
user data.
When a fault is detected on the active line, all customer traffic is
switched to the "SFP B" port. With non-Revertive mode data is
not resumed by "SFP A" port until SFP B fails or is disconnected.
1+1 SFP
In this mode, the "SFP A" port (fiber or copper) is connected
Protection
through the switch to the drop ports as the main link. The "SFP B"
Revertive
port (fiber or copper) is active into the MAC switch, but no
mode
connection inside the switch is made; in this way, the "SFP B" line
is held as the standby line. The "SFP B" line is held in the LINK
state for testing and line verification, but does not actively carry
user data.
When a fault is detected on the active line, all customer traffic is
switched to the "SFP B" port. Once the "A" port is no longer in a
fault condition, data is resumed on that port.
Revertive and Non-Revertive modes can only operate on the ports with SFPs, not the fixed
copper ports.
Description
NOTE
