Once the user has configured the MD, MA and at least one MEP, a particular
instance of an MEP can be accessed for more detailed configuration. To access a
particular instance of an MEP, click on the row containing the desired MEP as shown
below:
The current state of the MEP is shown by the color in the "State" column.
Color
Green
Correctly functioning MEP—all MEP's are active and sending CCMs
Red
Idle state or problem associated with the MEP
Yellow
Not all peer MEP CCMs are being received.
Moving the mouse over the displayed color displays a comment giving additional
information about the current state. Valid comments are:
•
MEP is Idle
•
MEP is Active
•
Remote MEP Idle
•
Remote MEP Failed
Description
38
