  • Page 1 Chipsmall Limited consists of a professional team with an average of over 10 year of expertise in the distribution of electronic components. Based in Hongkong, we have already established firm and mutual-benefit business relationships with customers from,Europe,America and south Asia,supplying obsolete and hard-to-find components to meet their specific needs.
  • Page 2 UDS1100 Device Server User Guide Part Number 900-417 Revision H December 2017...

  • Page 3: Intellectual Property

    Intellectual Property © 2017 Lantronix. All rights reserved. No part of the contents of this book may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Lantronix is a registered trademark and DeviceInstaller is a trademark of Lantronix.

  • Page 4: Revision History

    Revision History Date Rev. Comments February 2006 Initial document. June 2006 Changes to operating and storage temperatures. April 2007 Updated to add UDS1100-POE version. August 2008 Updated for firmware v6.6 . August 2012 Updated for firmware v6.8. December 2012 Updated operating temperature range. June 2015 Updated for firmware version 6.11.0.0.

  • Page 5: Table Of Contents

    Table of Contents Intellectual Property ____________________________________________ 2 Warranty _____________________________________________________ 2 Contacts _____________________________________________________ 2 Disclaimer ____________________________________________________ 2 Revision History _______________________________________________ 3 List of Figures _________________________________________________ 8 List of Tables _________________________________________________ 8 1: Using This Guide Purpose and Audience __________________________________________ 9 Chapter Summary _____________________________________________ 9 Additional Documentation ______________________________________ 10 2: Introduction Applications _________________________________________________ 11...
  • Page 6 Host List Configuration _________________________________________ 29 Channel 1 Configuration ________________________________________ 30 Serial Settings ____________________________________________ 30 Connection Settings - TCP ___________________________________ 33 Connection Settings - UDP ___________________________________ 36 Apply Settings _______________________________________________ 37 Apply Defaults _______________________________________________ 37 6: Configuration via Telnet or Serial Port (Setup Mode) Accessing Setup Mode _________________________________________ 39 Telnet Connection _________________________________________ 39 Serial Port Connection ______________________________________ 40...
  • Page 7 Entering Monitor Mode Using the Serial Port _____________________ 68 Entering Monitor Mode Using the Network Port ___________________ 68 Monitor Mode Commands ___________________________________ 68 A: Troubleshooting and Contact Information LEDs _______________________________________________________ 71 Problems and Error Messages ___________________________________ 72 Lantronix Technical Support _____________________________________ 74 UDS1100 Device Server User Guide...
  • Page 8 B: Connections and Pinouts Serial Port ___________________________________________________ 75 Serial Connector Pinouts _______________________________________ 75 Modem Cable ________________________________________________ 76 Network Port _________________________________________________ 77 Ethernet Connector Pinouts _____________________________________ 78 Power Plug __________________________________________________ 78 C: Technical Specifications D: Mounting Brackets E: Alternative Ways to Assign an IP Address DHCP ______________________________________________________ 82 AutoIP ______________________________________________________ 82 BOOTP _____________________________________________________ 83...

  • Page 9: List Of Figures

    Figure B-3. DB25 Female Interface RS422 (4 wire mode) ______________________ 76 Figure B-4. DB25 Female Interface RS485 (2 wire mode) ______________________ 76 Figure B-5. Wiring Diagram for Lantronix Modem Cable, Part No. 500-163 ________ 77 List of Tables Table 7-1. BootP/DHCP/AutoIP options ____________________________________ 42 Table 7-2.

  • Page 10: 1: Using This Guide

    1: Using This Guide Purpose and Audience This guide provides the information needed to configure, use, and update the Lantronix® UDS1100 device server. It is for system administrators and those responsible for installing and maintaining the UDS. Chapter Summary The remaining chapters in this guide include:...

  • Page 11: Additional Documentation

    Provides the steps for getting the UDS1100 up and running. DeviceInstaller Online Provides instructions for using the Windows-based utility to Help configure the UDS1100 and other Lantronix device servers. “Live” Tutorials on the Explain and demonstrate assigning an IP address to the UDS Lantronix Web Site and setting up the UDS and Com Port Redirector.

  • Page 12: 2: Introduction

    2: Introduction 2: Introduction The UDS1100 is a single-port device server that provides a quick, simple, and cost-effective way to bring the advantages of data accessibility and remote management to devices not currently connected to a network. Applications The UDS family of Device Servers allows serial devices, such as those listed below, to connect and communicate over Ethernet networks using the IP protocol family (TCP for connection-oriented stream applications and UDP for datagram applications).
  • Page 13 Figure 2-2. Direct TCP/IP or Redirector Configuration Personal Computer (PC) POS Device Note: For step-by-step instructions on configuring the UDS for serial tunneling or for use with the Com Port Redirector, see UDS Configuration Tutorials on the Lantronix web site: www.lantronix.com/support. UDS1100 Device Server User Guide...

  • Page 14: Protocol Support

    (See 4: Using DeviceInstaller.) Web-Manager: Through a web browser, configure the UDS settings using the Lantronix Web-Manager. (See 5: Configuration Using Web-Manager.) Serial and Telnet Ports: Use Setup Mode, a command line interface. There are two approaches to accessing Setup Mode: making a Telnet connection to the network port (9999) or connecting a terminal (or a PC running a terminal emulation program) to the unit’s serial port.

  • Page 15: Product Information Label

    2: Introduction Product Information Label The product information label on the underside of the unit contains the following information about your specific unit: Bar code  Part Number  Revision  Manufacturing Date Code  Serial number  Figure 2-3. Product Label Bar Code Part Number Manufacturing...

  • Page 16: 3: Installation Of Uds1100

    3: Installation of UDS1100 This chapter describes how to install your UDS1100 and get it up and running in the shortest possible time. Package Contents Verify and inspect the contents of the UDS1100 package using the following list. If any item is missing or damaged, contact your place of purchase immediately. UDS1100 ...
  • Page 17 3: Installation of UDS1100 Figure 3-2. Standard UDS1100 Connected to Serial Device and Network To install the unit: Complete the following steps in order. Refer to the numbers in the figure above. Note: See the sections that follow for details about connectors and pinouts.

  • Page 18: Required Information

    4: Using DeviceInstaller Required Information Before configuring the UDS, have the following information available: Hardware Address Take note of the unit’s hardware address (also known as the Ethernet or MAC address). It is on the product label (see Product Information Label).

  • Page 19: Installing Deviceinstaller

    The DeviceInstaller™application is a free utility program provided by Lantronix that discovers, configures, upgrades, and manages Lantronix Device Servers. It can be downloaded from the Lantronix website at www.lantronix.com/support/downloads. For instructions on using DeviceInstaller to configure the IP address and related settings or for more advanced features, see the DeviceInstaller Online Help.

  • Page 20: Adding The Unit To The Manage List

    Click the Close button to close the dialog box and return to the main window. Adding the Unit to the Manage List Now add the unit to the list of similar Lantronix devices on the network so you can manage and configure it. To perform this step, click the Search icon DeviceInstaller locates the unit and adds it to the list.
  • Page 21 4: Using DeviceInstaller DHCP Device Name Non-configurable field. Displays the name associated with UDS1100’s current IP address, if the IP address was obtained dynamically. To change the DHCP device name, see Configuration Using Web-Manager or Configuration via Telnet or Serial Port (Setup Mode).

  • Page 22: Next Step

    4: Using DeviceInstaller Number of COB Non-configurable field. Displays the number of COB partitions partitions supported supported. Number of Ports Non-configurable field. Displays the number of ports on the UDS1100. TCP Keepalive Non-configurable field. Displays the UDS1100’s TCP keepalive value. The value is in the range 1-65s, and the default setting is 45.

  • Page 23: Assigning The Ip Address: Serial Port Login

    4: Using DeviceInstaller  To configure the unit using a Web browser, click the Web Configuration tab. The Lantronix Web-Manager window displays in your browser. Continue with 5: Configuration Using Web-Manager. Note: To assign Expert and Security settings, you must use the Setup Mode window in a Telnet session.

  • Page 24: 5: Configuration Using Web-Manager

    For more information on DeviceInstaller, see Using DeviceInstaller. Run DeviceInstaller and search for the list of available Lantronix device servers. Click on the UDS folder. The list of available UDS products display. Expand the list of UDS1100s by clicking the + symbol next to the UDS1100 icon.
  • Page 25 We recommend that you always use the enhanced password setting and create a strong 16 character password. See Security Settings (Option 6) on page 61. Figure 5-2. Lantronix Web-Manager The main menu is in the left pane of the Web-Manager window. UDS1100 Device Server User Guide...

  • Page 26: Network Configuration

    5: Configuration Using Web-Manager Network Configuration The unit’s network values display when you select Network from the main menu. The following sections describe the configurable parameters on the Network Settings page. Figure 5-3. Network Settings Network Mode Click Network from the main menu. Note the following: Network Mode For the UDS1100, Wired Only is the only choice.
