Y (Yes) auto increment the source port. The xPico increments the port number used
with each new connection.

Remote IP Address

This is the destination IP address used with an outgoing connection.
Note: This option does not display when Hostlist is enabled from the ConnectMode
prompt (see

Remote Port

You must set the remote TCP port number for the unit to make outgoing connections.
This parameter defines the port number on the target host to which a connection is
attempted.
To connect an ASCII terminal to a host using the unit for login purposes, use the
remote port number 23 (Internet standard port number for Telnet services).
Note: This option does not display when Hostlist is enabled from the ConnectMode
prompt (see

DisConnMode

This setting determines the conditions under which the unit will cause a network
connection to terminate.
Notes:

In DisConnMode (Disconnect Mode), Modem Control In drop either drops the
connection or is ignored.

All bit positions in the table that are blank represent "don't care" bits, for that
particular option, which can be set to either a 0 or 1 value.
Disconnect Mode Option
Disconnect when Modem Control In is not asserted
Ignore Modem Control In
Telnet Com Port Cntrl and terminal type setup
Channel (port) password
Hard disconnect
Disable hard disconnect
xPico User Guide
Remote IP Address : (000) (000) (000) (000)_
Connect Mode on page 42 for more information).
Remote Port (0) ? _
Connect Mode on page 42 for more information).
DisConnMode (00) ? _

Table 7-9. Disconnect Mode Options

(2)
(3)
7: Setup Mode: Channel Configuration
7 6 5 4
(6)
1
0
(1)
1
1
3 2 1 0
0
1
