Table 11-1. Monitor Mode Commands - Lantronix xPico User Manual

Command
VS x.x.x.x
GC x.x.x.x
SC x.x.x.x
PI x.x.x.x
AT
TT
NC
RS
QU
G0, G1, ....,Ge, Gf
S0, S1,...,Se, Sf
GM
SS
SA
NS
co
Note: Entering any of the commands listed above generates one of the following
command response codes:
xPico User Guide

Table 11-1. Monitor Mode Commands

Command Name Function
Version Queries software header record (16 bytes) of unit
with IP address x.x.x.x.
Get Configuration Gets configuration of unit with IP address x.x.x.x as
hex records (120 bytes).
Send Configuration Sets configuration of unit with IP address x.x.x.x
from hex records.
Ping Pings unit with IP address x.x.x.x to check device
status.
ARP Table Shows the unit's ARP table entries.
TCP Connection Shows all incoming and outgoing TCP connections.
Table
Network Connection Shows the unit's IP address, gateway, subnet
mask, and DNS server.
Reset Resets the unit's power.
Quit Exits diagnostics mode.
Get configuration Gets a memory page of configuration information
from memory page from the device.
Set configuration to Sets a memory page of configuration information
memory page on the device.
Get MAC address Shows the unit's 6-byte MAC address.
Set Security record Sets the Security record without the encryption key
and length parameters. The entire record must still
be written, but the encryption-specific bytes do not
need to be provided (they can be null since they
are not overwritten).
Scan Initiates a wireless scan if the wireless interface is
enabled. Reports any stations found, including
BSSID, SSID, and RSSI. If SA is followed by a
string, the string is used to filter SSIDs before
reporting. If the BSS does not broadcast its SSID,
only the BSSID and RSSI are returned.
Network Status Reports the network interfaces' statuses. Includes
potentially negotiated parameters like speed/duplex
for Ethernet or BSSID, encryption, authentication
for wireless interfaces.
Set IP address, Example:
hostbits, gateway , co 192.168.0.10 8 192.168.0.1 10001 192.168.1.10
and DNS server IP with
192.168.0.10 = IP address of the xPico
8 = number of hostbits
192.168.0.1 = gateway IP address
10001 = port number of the xPico Channel 1
192.168.1.10 = IP address of the DNS Server
The xPico stores the setup and performs a reset. It
sends an X before the reset if the command was
OK.
11: Monitor Mode
71
