6. Setup Mode: Server Configuration

This chapter explains how to configure the network settings.
Note: Current values appear in parentheses.

Server Configuration (Option 0)

The unit's basic network parameters display when you select Server configuration
(option 0). The IP Address, Set Gateway IP Address, and Netmask fields display
the current values.

IP Address

If DHCP is not used to assign IP addresses, enter the IP address manually. The IP
address must be set to a unique value in the network. Enter each octet and press
Enter between each section. The current value displays in parentheses.
If DHCP is used, the third octet of the IP address sets the BootP/DHCP/AutoIP
options. The following table shows the bits you can manually configure to force the
xPico to disable AutoIP, DHCP, or BootP. To disable an option, set the appropriate
bit.
For example, if the third octet is 0.0.5.0, the AutoIP and BootP options are disabled;
only DHCP is enabled. (The value 5 results from adding the binary equivalents of 0
and 2.) This is the most common setting when using DHCP.
xPico User Guide
IP Address : (172) .(019) .(205) .(008)
Set Gateway IP Address (Y) ?
Gateway IP addr (172) .(019) .(000) .(001)
Netmask: Number of Bits for Host Part (0=default) (0)
Set DNS Server IP addr
Change Telnet/Web Manager password (N) ?
IP Address : ( 0) ( 0) ( 0) ( 0) _

Table 6-1. BootP/DHCP/AutoIP Options

Options
AutoIP
DHCP
BootP
(N) ?
Bit
0
1
2
