Network Mode

1. Click Network from the main menu.
2. Note the following:
Network Mode

Automatic IP Address Configuration

An IP address can be assigned automatically. You then enter related network
settings.
To assign an IP address automatically:
1. On the main menu, click Network.
2. Select Obtain IP address automatically.
3. Enter the following (as necessary):
BOOTP
DHCP
xPico User Guide
4: Configuration Using Web Manager

Figure 4-3. Network Settings

Wired Only is the only choice. It enables the Ethernet network
connectivity.
Select Enable to permit the Bootstrap Protocol (BOOTP).
server to assign the IP address from a pool of addresses
automatically. Enable is the default.
Select Enable to permit the Dynamic Host Configuration
20
