I/F (Interface) Mode

The Interface (I/F) Mode is a bit-coded byte entered in hexadecimal notation.
The following table displays available I/F Mode options:
Note: All bit positions in the table that are blank represent "don't care" bits for that
particular option, which can be set to either a 0 or 1 value.
(1) 2 stop bits are implemented by the software. This might influence performance.
The following table demonstrates how to build some common Interface Mode
settings:

Flow

Flow control sets the local handshaking method for stopping serial input/output.
Use the following table to select flow control options:
xPico User Guide
I/F Mode (4C) ? _

Table 7-1. Interface Mode Options

I/F Mode Option 7
(1)
RS-232C
RS-422/485
RS-485 2-wire
7 Bit
8 Bit
No Parity
Even Parity
Odd Parity
1 stop bit 0
(1)
2 stop bits 1

Table 7-2. RS232 Interface Mode Settings

Common I/F Mode Setting
RS-232C, 8-bit, No Parity, 1 stop bit
RS-232C, 7-bit, Even Parity, 1 stop bit
Flow (00) ? _
7: Setup Mode: Channel Configuration
6 5 4 3 2 1 0
0 0
0 1
1 1
1 0
1 1
0 0
1 1
0 1
1
1
Binary Hex
0100 1100 4C
0111 1000 78
