Obtaining Firmware

You can obtain the most up-to-date firmware and release notes for the unit from the
Lantronix Web site (http://www.lantronix.com/) or by using anonymous FTP
(ftp://ftp.lantronix.com/).

Reloading Firmware

There are several ways to update the unit's internal operational code (U200*.ROM or
U200*.HEX): using DeviceInstaller (the preferred way), TFTP, another unit, or a serial
port. You can also update the unit's internal Web interface (CBXW*.COB) using
TFTP or DeviceInstaller.

Using DeviceInstaller

After downloading the firmware to your computer, you can use DeviceInstaller to
install it.
1. Download the updated firmware files from www.lantronix.com or
ftp://ftp.lantronix.com/ and store them in a subfolder on your computer.
2. Click the Start button on the Task Bar and select Programs
DeviceInstaller
3. Click the Search the network for devices icon. The Search Network window
displays.
4. Once located by DeviceInstaller, highlight the device in the device list and click
the Upgrade button (which displays after you select the device). Select a custom
installation by specifying the individual files and clicking Next.
5. Click the Browse button to select the location of the firmware file to load, and
then click Next.
6. Select Do not copy or replace any files and click Next.
Note:
the Web Manager files (.COB).
7. Click Next again. The status of the upgrade displays in the window.
8. After the upgrade completes, click Close.
F i r m w a r e
F i r m w a r e
DeviceInstaller. The DeviceInstaller window displays.
This option upgrades the firmware file (.ROM file) only, not
37
