Introduction

Additional Features

Modem Emulation: In modem emulation mode, the UDS200 can replace dial-up
modems. The unit accepts modem AT commands on the serial port, and then
establishes a network connection to the end device, leveraging network connections
and bandwidth to eliminate dedicated modems and phone lines.
Built-in Web Server: The UDS200 includes a built-in web server for configuring the
unit and displaying operating and troubleshooting information on the attached links to
online support.

Configuration Methods

After installation, the UDS200 requires configuration. For the unit to operate correctly
on a network, it must have a unique IP address on the network. There are three basic
methods for logging into the UDS200 and assigning IP addresses and other
configurable settings:
DeviceInstaller: Configure the IP address and other network settings on the
UDS200 using a Graphical User Interface (GUI) on a PC attached to a network. See
DeviceInstaller on page 14.)
Web Manager: Through a web interface, configure the UDS200 settings using the
Lantronix Web Manager. (See
Serial and Telnet Ports: There are two approaches to accessing Setup Mode:
making a Telnet connection to the network port (9999) or connecting a terminal (or a
PC running a terminal emulation program) to the unit's serial port. (See
Configuring the UDS Using Telnet or the Serial

Product Information Label

The product information label on the underside of the unit contains the following
information about your specific unit:
The first three bytes of the hardware address are fixed and read 00-20-4A, identifying
the unit as a Lantronix product. The fourth, fifth, and sixth bytes are unique numbers
assigned to each unit.
4: Configuring the UDS Using Web
Bar code
Serial number
Product ID (name)
Product description
Hardware address (also referred to as Ethernet or MAC address)

Figure 2-2. Sample Hardware Address

00-20-4A-14-01-18 or 00:20:4A:14:01:18
Port.)
11
UDS200 User Guide
Manager.)
5:
