SYSTEM COMPONENTS

MODEL NAME
MR-1000RII
MR-1000TII
MR-1000TIII

SUPPLIED ACCESSORIES

• EX-2714 (Radome type unit)
q System cable (OPC-1188A: 15 m) ...................... 1
w Installation bolts (M10×50) .................................. 4
e Installation bolts (M10×25) .................................. 4
r Installation nuts (M10) ......................................... 4
t Flat washers (M10) .............................................. 4
y Spring washers (M10) ......................................... 4
• EX-2780 (Open array type unit)
q System cable (OPC-1189A: 20 m) ....................... 1
w Installation bolts (M10×40) .................................. 4
e Installation nuts (M10) ......................................... 4
r Flat washers (M10) .............................................. 4
t Spring washers (M10) ......................................... 4
y Hex head wrench ................................................. 1
u Cap bolts (M8×18) ............................................... 4
i Dish washers (M8) ............................................... 4
o Sealing washers (T) ............................................. 4
!0 Flat washers (M8) ................................................ 4
!1 Grounding terminal (R5.5-10) .............................. 1
!2 Ferrite bead ......................................................... 1
Icom, Icom Inc. and the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
i
CRT DISPLAY
SX-2713 (10-inch CRT)
SX-2779 (10-inch CRT)
SX-2779 (10-inch CRT)
Qty.
Qty.
logo are registered trademarks of Icom Incorporated (Japan) in the United states, the
EX-2714 (Radome type)
EX-2780 (Open array type; 4 kW)
EX-2780 (Open array type; 6 kW)
• SX-2713/2779 (10 inch CRT display unit)
q NMEA connector (FM14-8P) ................................ 1
w Spare fuse (FGB 10 A) ........................................ 1
e Spare fuse (FGB 5 A: for over 24 V power supply)
............................................................................ 1
r DC power cable (OPC-928-2) .............................. 1
t Viewing hood (2363 HOOD) ................................. 1
y Mounting bracket (2363 ANGLE(A))..................... 1
u Mounting screw knobs (2363 KNOB BOLT) ......... 2
i Self-tapping screws (M6 × 30).............................. 5
o Spring washers (M6) ........................................... 5
!0 Flat washers (M6) ................................................ 5
!1 Instruction manual ............................................... 1
!2 Operating guide ................................................... 1
!3 NMEA connector (FM14-7P) ............................... 1
SCANNER UNIT
Qty.
