FOREWORD

Thank you for purchasing Icom's MXR-5000R/T
.
rine radar
The radar is designed for use with the Icom Marine-
Commander™ system through the supplied connection
cable.
It has powerful transmission power, and many other
advanced features can be used with the Icom Marine-
Commander™ system.

IMPORTANT

READ THIS INSTRUCTION MANUAL
CAREFULLY
before attempting to operate the
radar.
SAVE THIS INSTRUCTION MANUAL.
manual contains important safety and operating
instructions for the MXR-5000R/T.

SYSTEM COMPONENTS

MODEL NAME
MXR-5000R
(Radar)
MXR-5000T
(Radar)

EXPLICIT DEFINITIONS

WORD
Personal death, serious injury or an explo-
RDANGER!
sion may occur.
Personal injury, fire hazard or electric
RWARNING!
shock may occur.
Equipment damage may occur.
CAUTION
If disregarded, inconvenience only. No risk
NOTE
of personal injury, fire or electric shock.
The MXR-5000R/T are supplemental aids to navi-
gation and are not intended to be a substitute for
accurate and current nautical charts.
Icom, Icom Inc. and the Icom logo are registered trademarks of
Icom Incorporated (Japan) in Japan, the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other countries.
MarineCommander is a trademark of Icom Incorporated.
All other products or brands are registered trademarks or trade-
marks of their respective holders.
i i
UNIT SCANNER UNIT
EX-2714
Radar unit
(Radome type)
EX-2780
Radar unit
(Open array type)
DEFINITION

SUPPLIED ACCESSORIES

-
ma
• DC power cable .......................................................... 1
• Connection cable ........................................................ 1
• Spring washers (M5) .................................................. 8
• Flat washers (M5) ...................................................... 8
• Nuts (M5) ................................................................... 4
• Bolts (M5×30 mm) ...................................................... 4
• Fuse (FGB 5 A for 24 V power source) ...................... 1
• Spare fuse (FGB 10 A for 12 V power source) ........... 1
• Scanner unit ......................................................... 1 set
EX-2714 (Radome type) for MXR-5000R
- System cable (OPC-1188A: 15 m) ........................... 1
- Bolts (M10×50 mm) .................................................. 4
- Bolts (M10×25 mm) .................................................. 4
- Nuts (M10) ............................................................... 4
- Flat washers (M10) .................................................. 4
- Spring washers (M10) .............................................. 4
This EX-2780 (Open array type) for MXR-5000T
- System cable (OPC-1189A: 20 m) ............................ 1
- Bolts (M10×40 mm) .................................................. 4
- Nuts (M10) ............................................................... 4
- Flat washers (M10) .................................................. 4
- Spring washers (M10) .............................................. 4
- Allen wrench ............................................................. 1
- Cap bolts (M8×18 mm) ............................................. 4
- Belleville washers (M8) ............................................ 4
- Sealing washers (T) ................................................. 4
- Flat washers (M8) .................................................... 4
- Grounding terminal (R5.5-10) .................................. 1
- Ferrite EMI filter ........................................................ 1

FCC INFORMATION

• FOR CLASS A UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
Qty.
