The following references a b c
etc., refer to the drawing on page 10.

4.1 External unit

a Connect the LNB input of the digital receiver to the LNB of your external unit with a
suitable coax cable. Please also note Section 6 "Settings".

4.2 Connecting to a TV set

b Connect the receiver (SCART socket TV) and TV set (SCART socket) with a
SCART cable. If appropriately equipped, your television set will automatically switch
to AV and therefore to receiver operation when the digital receiver is turned on.

4.3 Video cassette recorder (VCR)

c Connect the video cassette recorder to the SCART socket VCR. The video cassette
recorder provides a switch signal to the digital receiver during playback. This enables
the video cassette recorder signal to be sent to the TV set automatically.If your video
cassette recorder does not supply a switching voltage, switch your digital receiver to
the external AV input by means of the key EXTERN key. Return to normal operation
by pressing this key again.
4.4 HiFi amplifier

4.4.1 Analogue

d To achieve the best possible sound quality, you can connect the digital receiver to a
HiFi amplifier. For this, connect the cinch socket Audio R and Audio L of the digital
receiver by means of a suitable cable to an input of your HiFi amplifier (e.g. CD or
AUX; Careful, the phono input is not suitable!).

4.4.2 Digital

d Should your amplifier have an appropriate electrical or optical input, connect the sok-
ket AUDIO OUT DIGITAL electrical or AUDIO OUT DIGITAL optical to the
electrical or optical input of your amplifier.
The sampling rates 32, 44.1 and 48 kHz are available depending on the respective station.
The Dolby digital signal (AC3) is also available at this output, if broadcast.

4.5 Serial interface (RS 232)

The RS 232 interface enables updating the system software and preprogramming via the PC.

4.6 Mains connection

The digital receiver should only be connected to the mains after the device has been con-
nected to all appropriate components. This prevents destruction of the digital receiver or of
other components.
e After making all connections, connect the receiver to a power socket 230 V/50-60 Hz
with the enclosed power cable.
