6.3.3 Subtitlelanguage

You can display subtitles with your DVB receiver. These are automatically displayed, if the
subtitle function is turned on and the specified language is broadcast..
The subtitles can be turned on manually, if this function is not activated. Available subtitles
are indicated by the Subtitle selection indication. Please also note Section 7.13 of the
operating manual

6.3.4 TV SCART mode

Set FBAS, RGB or S-Video in this line with the arrow keys left/right corresponding to
your TV set. Set FBAS for standard appliances.

6.3.5 VCR SCART mode

Set FBAS, RGB or S-Video in this line with the arrow keys left/right corresponding to
your TV set. Set FBAS for standard appliances.

6.3.6 Dolby Digital (AC3)

Various films are broadcast in Dolby Digital format. This is indicated by the Dolby sign
the info window after setting a channel.
Should you have a Dolby Digital 5.1 channel amplifier you can hear the relevant films in 5.1-
channel Dolby digital sound, if broadcast in this mode. The only precondition for this is a con-
nection between the Audio Out Digital digital output (see Section 4.5.2) of your DVB receiver
and the digital input of your Dolby Digital 5.1 channel amplifier.
A broadcast transmitted in Dolby Digital Sound is indicated in the infobox by the Dolby sign
when turning the channel on. If the function Dolby Digital (AC3) has been activated (on),
these channels are broadcast in Dolby Digital format automatically.
If the function is not activated, the Dolby Digital Sound can be turned on manually, (off).
Please also note Section 7.6.1 of the operating manual.
Accept settings
In order to save the settings made in this menu, please proceed as follows:
> Pressing the green control key Accept will save the changes carried out and will
return you to the Settings menu
alternatively:
> Press the red function key Return. Now, a query will be displayed.
> Mark the field YES with the arrow keys right/left, if you would like to accept thje
changes, confirm with OK. This will return you to the previous menu.
> Return to normal operation by pressing the TV/Radio key. The settings will be saved
automatically.
