Support via interposer Mott
®
Intel High
Definition
Canyon 4 daughter card (support
Audio MDC
via sideband cable)
Header
14 USB 2.0/1.1 Ports
USB
One LPC slot
LPC
H8S/2117 micro-controller
Two PS/2 ports
SMC/KBC
One scan matrix keyboard
connector
CK-505 system
Clocks
Battery-backed Real Time Clock
RTC
IMVP-6.5 for Processor core
Processor
Voltage
Regulator
Power
Supply
Processor and Chipset XDP
Debug
Interfaces
Port 80 display
®
Intel Active Management
Intel ® AMT
support
Technology 6.0
ACPI Compliant
Power
Management
ATX 2.2 like form factor
Form Factor

3.4 Driver Key Features

The driver CD included in the kit contains all software drivers necessary for basic system
functionality for various operating systems. The CD contains the production drivers that were
released in conjunction with the launch of this platform. However, it is possible that these
drivers have been updated since then. Please check for updated drivers at
http://platformsw.intel.com.
Dev Kit Manual
Description Comments
Soft Audio/Soft Modem
1 Quad USB connector
1 dual USB connector on RJ45
8 ports available as FPIOs
Optional routing to docking for USB lane 4
Over Current protection provided in Pairs.
Floater OC7# used as SMC_WAKE_SCI#
Includes sideband headers
ACPI compliant
Supports Buffer Through Mode only.
IMVP 6.5 Compliant CPU Core and Graphics
Core VRs, Manual Override Option for VIDs
available on both VR Controllers.
ATX Power Supply
On board Processor Chipset XDP Ports
Port 80 Through Add-in card. Four seven-
segment displays
Supported C states: C0, C1, C1E, C3, C6,
C7
10 layer board – 12" x 11.2"
