Paper Properties
Paper manufactured from 100% chemical wood pulp
containing no more than 25% cotton fiber is
recommended. Paper should be dust-free and have
cleanly cut edges. Do not use wrinkled, curled, or
damp paper; it often causes misfeeds, paper jams, and
illegible output.
Most printing paper has two sides: top, often called
the "felt" side, and bottom, or "wire" side. The
package label generally has an arrow showing you
how to load paper so that output goes to the wire side.
NEC has tested Xerox® 4024
obtained satisfactory results. Generally, paper
manufactured for photocopying has good print
quality and paper-handling characteristics.
Note: Paper properties can be changed by the
manufacturers. NEC has no control over such
changes. Thus NEC neither warrants nor
recommends the use of any particular paper and
the user assumes all responsibility for the quality
and performance of paper selected.
No matter which manufacturer you select, note the
following considerations.
•
Smoother surface paper generates sharper output
resolution and detail.
•
Coated paper can melt, discolor, or release
hazardous emissions at temperatures greater than
392°F (200°C).
11 App.D Media*
3
(20 lb.) paper and
TM
Appendix D: Selecting Print Media
•
The acceptable range of media weight for use is 16
to 28 lbs (60 to 105 g/m
2
).
Print Areas
Acceptable media sizes and their print areas are as
follows:
•
Letter 8.5 in. x 11 in.
print area 8.0 in. x 10.5 in.
(216 mm x 279 mm)
(203 mm x 267 mm)
•
Legal 8.5 in. x 14 in.
print area 8.0 in. x 13.5 in.
(216 mm x 356 mm)
(203 mm x 343 mm)
•
Monarch Envelopes
3.875 in. x 7.5 in.
print area 3.2 in. x 6.9 in.
(98.4 mm x 190.5 mm) (82.4 mm x 174.5 mm)
•
Commercial Envelopes
10 4.125 in. x 9.5 in.
print area 3.5 in. x 8.9 in.
(105 mm x 241 mm)
(89 mm x 225 mm)
•
International DL Envelopes
110 mm x 220 mm
print area 3.70 in. x 8.03 in.
(4.22 in. x 8.66 in.)
(94 mm x 204 mm)
•
International C5 Envelopes
6.38 in. x 9.02 in.
print area 5.75 in. x 8.39 in.
(162 mm x 229 mm)
(146 mm x 213 mm)
Load envelopes face up, with the narrow side in first.
The flap should be down and to the left. Refer to the
Paper Loading sticker included in the printer
accessories kit.
96.9.24, 1:22 PM
D—3
