ICON DESCRIPTION
Toner Saving Mode: Allows you to save toner
by controlling print density. You can select on or
off. Default is off. Not available when SET is on.
.
Sharp Edge Technology: SuperScript features
the patented Sharp Edge SET Technology .
This feature detects and smooths the jagged
edges of vectors by dividing one full dot into
several subdots set in the same area. The print
quality of both text and line graphics is thus
improved. Default is on. Not available when
Toner Saving is on.
Print Darkness/Line Width: Allows you to
control the line width darkness (not images).
You can set this mode to light, medium, or dark.
Default is medium.
Page Save Mode: When enabled, the current
page is saved in memory until printing is
complete. Enable for sensitive documents where
loss of data cannot be tolerated. Disable this
feature to increase throughput. Default is off.
Power Saving Mode: This printer has Power
Saving Mode. In this mode, if the printer is idle
for a specified time, the fuser unit pauses and
power consumption is decreased. Default is off.
Printer Setup: Allows you to set up the printer.
Clicking this icon displays a setup screen for the
printing mode currently selected. (Refer to the
next section on the GDI Setup Window.)
05 Ch.4 Console 3
Table 4.1 SuperScript Control Panel Buttons
Chapter 4: SuperScript Console
ICON DESCRIPTION
Connect Port: Identifies the port to which your
printer is connected, such as LPT1.
PCL Control Panel: Displays the PCL Control
Panel menu that is used to set up PCL mode
when printing from a DOS file.
DOS Printing Option: Allows you to select a
printing mode for printing from DOS within
Windows. Refer to the section on DOS printing
in this chapter.
Status Report Options: Provides status report
options. You can select from the following
options: Minimize Printer Status Display
Beep When a Job is Complete
Beep on Printer Error
Note: This item is specific to NEC peer to peer
sharing and may not be functional. NEC developed a
proprietary sharing system for environments with
multiple NEC SuperScript printers. For most
environments, standard Windows sharing is more
suitable and the NEC SuperScript 660plus is fully
compatible.
Print Test Page: Outputs the printer test page.
You can test the connection between your PC
and the SuperScript printer by this function.
96.9.24, 11:56 AM
4—3
