NEC SuperScript 660plus User Manual page 67

4. Hold the module so that the notch is on the right
and the metal edge faces toward the memory
socket.
5. Hold the module at an angle and push it firmly
into the socket.
10 App.C Options* 5
Appendix C: Printer Options
6. Press the module up until you hear a click as it
snaps into place. Check that the module is held in
place securely by the metal holders on each side.
7. Replace the memory cover. First insert the memory
cover downward into the printer, then move it to its
original position. Next, using a coin, tighten the
screw by turning in the direction of the arrow.
Caution! Check that the memory cover is firmly
secured.
96.9.24, 1:16 PM
C—5
