HP PROCURVE 2610 Advanced Traffic Management Manual page 222

Quality of Service (QoS): Managing Bandwidth More Effectively
Using QoS Classifiers To Configure QoS for Outbound Traffic
For example, suppose you wanted to assign these DSCP policies to the packets
identified by the indicated IP addresses:
1. Determine whether the DSCPs already have priority assignments, which
Figure 6-11. Display the Current DSCP-Map Configuration
6-32
no qos device-priority < ip-address >
Deletes the specified IP address as a QoS classifier.
show qos device-priority
Displays a listing of all QoS Device Priority classifiers
currently in the running-config file.
IP Address
10.28.31.1
10.28.31.130
10.28.31.100
10.28.31.101
could indicate use by existing applications. This is not a problem if the
configured priorities are acceptable for all applications using the same
DSCP. (Refer to the "Note On Changing a Priority Setting" on page 6-61.
Also, a DSCP must have a priority configured before you can assign any
QoS classifiers to use it.)
DSCP Policies
DSCP Priority
000111 7
000101 5
000010 1
000010 1
The DSCPs for this
example have not yet
been assigned an
802.1p priority level.
