Spanning-Tree Operation
802.1D Spanning-Tree Protocol (STP)
To View and/or Configure Fast-Uplink STP. This procedure uses the
Spanning Tree Operation screen to enable STP and to set the Mode for fast-
uplink STP operation.
1. From the Main Menu select:
2. In the default STP configuration, RSTP is the selected protocol version.
Figure 5-15. The Default STP Screen With the Protocol Version Field Set to "RSTP"
5-36
2. Switch Configuration ...
4. Spanning Tree Operation
If this is the case on your switch, you must change the Protocol Version
to STP in order to use Fast-Uplink STP:
• If the Protocol Version is set to RSTP (the default, as shown in this
example, go to step 3.
• If the Protocol Version is set to STP, the rest of the screen will appear
as shown in figure 5-17. In this case, go to step 4 on page 5-38.
