3. Enter the deny command to create a rule in the MAC ACL to drop traffic with the source MAC
4. Enter the permit command to create a rule in the MAC ACL to permit traffic with the source
5. Use the seq command to create MAC ACL rules in a specific sequence.

Creating an extended MAC ACL and adding rules

NOTE
You can use the resequence command to change all the sequence numbers assigned to the rules
in a MAC ACL. For detailed information, see
page 104.
The MAC ACL name length is limited to 64 characters.
To create an extended MAC ACL and add rules, perform the following steps from privileged EXEC
mode.
1. Enter the configure terminal command to access global configuration mode.
2. Create an extended MAC ACL and enter ACL configuration mode.
3. Create a rule in the MAC ACL to permit traffic with the source MAC address and the destination
4. Use the seq command to insert the rule anywhere in the MAC ACL.
5. Enter the copy command to save the running-config file to the startup-config file.

Modifying MAC ACL rules

You cannot modify the existing rules of a MAC ACL. However, you can remove the rule and then
recreate it with the desired changes.
If you need to add more rules between existing rules than the current sequence numbering allows,
you can use the resequence command to reassign sequence numbers. For detailed information,
see
Use a sequence number to specify the rule you wish to modify. Without a sequence number, a new
rule is added to the end of the list, and the existing rule is unchanged.
Converged Enhanced Ethernet Administrator's Guide
53-1002163-02
DRAFT: BROCADE CONFIDENTIAL
address.
switch(conf-macl-std)#deny 0022.3333.4444 count
MAC address.
switch(conf-macl-std)#permit 0022.5555.3333 count
switch(conf-macl-std)#seq 100 deny 0011.2222.3333 count
switch(conf-macl-std)#seq 1000 permit 0022.1111.2222 count
switch(config)#mac access-list extended test_02
MAC address.
switch(conf-macl-ext)#permit 0022.3333.4444 0022.3333.5555
switch(conf-macl-std)#seq 5 permit 0022.3333.4444 0022.3333.5555
switch(conf-macl-std)#do copy running-config startup-config
"Reordering the sequence numbers in a MAC ACL"
ACL configuration and management
"Reordering the sequence numbers in a MAC ACL"
on page 104.
