- Page 1 53-1001235-02 April 10, 2009 Power Supply Replacement Procedure Supporting the Brocade Encryption Switch and 8000 53-1001235-02 *53-1001235-02* April 10, 2009...
- Page 2 United States government. The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that accompany it.
-
Page 3: Power Supply Replacement
Power supply replacement The Brocade Encryption Switch and the Brocade 8000 share the same power supplies and each has two power supplies, as displayed in Figure 1 Figure Power supply 1 Power supply 2 FIGURE 1 Location of power supplies for the Brocade 8000... -
Page 4: Time Required
Table 1 Power supply status LED behavior, description, and required actions LED Color Description Action Required No light Power supply is not receiving power, or is off. Verify that the power supply is on and seated and the power cord is connected to a functioning power source. - Page 5 a. Orient the power supply as shown in Figure 3, with the AC power switch on the left. b. Gently push the power supply into the chassis until it is firmly seated. Secure the power supply to the chassis by screwing in the captive screw using the Phillips-head screwdriver. Plug the power cord in to the power supply and power on the unit by pressing the AC power switch to the “1”...
- Page 6 Power Supply Replacement Procedure 53-1001235-02...
