Chapter 1: Introduction
Remote Data Transfer enables the operator to work from a remote site where he
can control several PowerMax/PowerMaster systems at different installation sites.
Using the Remote Programmer, he can compare the parameters of the different
systems and copy them if necessary. The data is then transferred to each system
through a modem.
COMPUTER
Figure 1-2: Setup for Remote Data Transfer with an External Modem
COMPUTER
Figure 1-3: Setup for Remote Data Transfer with an Internal Modem
2
REMOTE SETUP-
EXTERNA L MODEM
TEL. LINE
EXTERNAL
MODEM
RS-232 CABLE
REMOTE SETUP-
INTERNA L MODEM
TEL. LINE
MODEM'S LINE JACK
DE5450S Remote Programmer Guide Rev. 8
POWERMASTER-10
POWERMASTER-10
