AOpen AP5TC User Manual page 88

Frequently Asked Questions
Q: What is the memory performance improvement of TX chipset?
A: Following is the compare table of TX+SDRAM, VX+SDRAM, TX+EDO,
HX+EDO and VX+EDO.
CPU : Pentium PP/MT (P55C) 200MHz
DRAM :16MB EDO or SDRAM
HDD : Quantum Fireball 1280AT
VGA : AOpen PV60 S3 Trio64V+ 800x600x256 Small font
OS : Windows 95 OSR2
Chipset Model
Intel 430VX AP5VM
Intel 430HX AP53/AP5K
Intel 430TX AP5T/AX5T
Intel 430VX AP5VM/AP5V
Intel 430TX AP5T/AX5T
Q: Power Management Icon does not appear in the Windows 95 Control
Panel even though the APM under BIOS Setup is enabled.
A: This problem occurs if you did not enable the APM function before you
install Windows 95. If you have already installed Windows 95, re-install it
after the BIOS APM function is enabled.
A-6
DRAM Timing
EDO 6-2-2-2
EDO 5-2-2-2
EDO 5-2-2-2
SDRAM 6-1-1-1
SDRAM 5-1-1-1
Winstone9
6
86.1
86.8
87.3
86.6
87.7
