AOpen AX4G Easy Installation Manual

AOpen AX4G Easy Installation Manual

Hide thumbs Also See for AX4G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Online Manual
Intel 82562ET (Kinnereth) PHY
(For AX4G-N only)
Front Audio Connector
Onboard AC'97 CODEC
MODEM-CN Connector
S/PDIF Connector
CD-IN Connector
CNR Expansion Slot
32-bit PCI Expansion Slot x6
WOL (Wake on LAN) Connector
nd
rd
Supports 2
& 3
USB (2.0) Connector
JP28 Keyboard/Mouse Wakeup
Enable/Disable Jumper
Chassis Intrusion Connector
WOM (Wake on Modem) Connector
JP14 CMOS Clear Jumper
Front Panel Connector
FAN3 Connector
Dr. LED Connector
COM2 Connector
4Mbit Flash ROM
PS/2 Mouse
SPP/EPP/ECP Parallel Port
Connector
PS/2 Keyboard
COM 1 Port
VGA Port
Connector
RJ45 10/100
LAN Jack
MIDI/Game Port
(AX4G-N only)
USB Port
(2.0)
MIC-In
Line-In
Speaker Out
Resetable Fuse
FAN2 Connector
2200
F Low ESR Capacitors
μ
4-pin 12V. ATX Power Connector
AGP 4X Expansion Slot
(For 1.5V AGP card or ADD card only)
478-pin CPU socket with Voltage and
Frequency Auto-detection that supports
®
®
Intel
Pentium
4 1.4~2.4GHz+ CPU
(Willamette and Northwood)
®
Intel
845G chipset (Brookdale-G)
CPU Fan Connector with H/W
Monitoring Function
184-pin DIMMx3 supports
DDR333/DDR266/DDR200
(Max. to 2GB)
IrDA Connector
ATX Power Connector
FDD Connector
ATA/33/66/100 IDE Connector x2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX4G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AOpen AX4G

Summary of Contents for AOpen AX4G

  • Page 1 MIDI/Game Port (AX4G-N only) Connector USB Port PS/2 Keyboard Intel 82562ET (Kinnereth) PHY COM 1 Port VGA Port (2.0) Connector (For AX4G-N only) Front Audio Connector MIC-In Onboard AC’97 CODEC Line-In Speaker Out MODEM-CN Connector S/PDIF Connector Resetable Fuse CD-IN Connector...

  • Page 2: Jp14 Clear Cmos

    1. JP14 Clear CMOS You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. 1. Turn off the system and unplug the AC power. 2. Remove ATX power cable from connector PWR2. Everything you need to boot this 3.

  • Page 3: Connecting Front Panel Cable

    3. Installing CPU & System Fan 5. Setting CPU Voltage & Frequency CPU Core Voltage Auto Detectable Plug in the CPU fan cable to the 3-pin CPU FAN connector. If you have chassis fan, you The CPU core voltage will be automatically detected. It is not necessary to set CPU core can also plug it on System Fan (FAN2) or FAN3 (AUX Fan) connector.

  • Page 4: Support Six Usb2.0 Connectors

    6. Support Six USB2.0 Connectors 8. Connecting IDE and Floppy Cables This motherboard provides six USB2.0 connectors. Compared to traditional USB 1.0/1.1 Connect 34-pin floppy cable and 40-pin, 80-wire IDE cable to floppy connector FDC and with the speed of 12Mbps, USB 2.0 has a fancy speed up to 480Mbps, which is 40 times IDE connector.

  • Page 5: Bios Upgrade Under Windows Environment

    The South Bridge ICH4 includes a fast Ethernet controller on chip. On the strength of Intel With outstanding R&D ability of AOpen, we now bring you a whole new BIOS Flash wizard 82562 (Kinnereth) PHY on board, which is a highly-integrated Platform LAN Connect device, ---- EZWinFlash.

  • Page 6: Bios Upgrade

    14. AOpen Bonus Pack CD 16. BIOS Upgrade AOpen Easy Flash is more user-friendly than traditional flash method. The BIOS binary You can use the autorun menu of Bonus CD disc. Choose the utility and driver and select file and flash routine are combined together and you simply run a single file to complete model name.

  • Page 7: Part Number And Serial Number

    IDE cable. The problem should be caused by the Check if the system can IDE cables or HDD itself. reboot successfully. Re-install Windows 95, Windows 98 or Windows NT. AX4G-N is model name of motherboard; R1.02 is BIOS version...
  • Page 8 Dear Customer, Test Report: We recommend to choose board/card/device from the Thanks for choosing AOpen products. To provide the best and fastest service to compatibility test reports for assembling your PC. our customer is our first priority. However, we receive numerous emails and http://www.aopen.com/tech/report/default.htm...

This manual is also suitable for:

Ax4g-n
