Technical Information

Interface – AGP Pro 110

Graphic controller – High-speed Wildcat chipset technology

DAC speed – 250 MHz

Data width – Frame buffer 256 bits; texture buffer 128 bits; DirectBurst 64 bits

Video memory – Frame buffer 128 MB; texture buffer 128 MB; DirectBurst 32 MB

Interrupts – PCI-assigned; Interrupt A for Wildcat 4210

DMA channels – PCI, AGP 2x

Connectors – Two DVI-I outputs; BNC connector; two 6-pin modular jacks; 3-pin miniDIN

stereo sync output

Dimensions – 2.20 in (5.6 cm) high x 13.34 in (33.9 cm) long by 4.25 in (10.8 cm) wide

Expansion slots – One AGP Pro 110 slot and two adjacent PCI slots (one for the on-board

power supply and one for cooling)

Power – 85 W maximum; 12.0 V 250 mA maximum; 5.0 V 9.8 A maximum; 3.3 V 10 A

maximum

Performance numbers reflect maximum hardware rate. Numbers may vary depending on the

application.

3D Gourad-shaded triangles, Z-buffered, 15-pixel – 12.0 M triangles/sec

3D Gourad-shaded triangles, Z-buffered, 25-pixel – 8.5 M triangles/sec

3D Vectors, solid color, 10-pixel – 17.6 M vectors/sec
