Technical Information; Hardware Specifications; Monitor Resolutions - Intergraph Intense3D Wildcat 4105 Hardware User's Manual

3

Technical Information

The following technical information is subject to change without notice.

Hardware Specifications

Item Specification
System AGP 2.0*
Card Size Full-length AGP card
*Although the Wildcat 4105 is a one-card solution that installs in your workstation's AGP slot, an
open adjacent PCI slot is needed for cooling purposes.

Monitor Resolutions

In the following tables, i indicates an interlaced frequency.
The Wildcat 4105 supports standard multiple-frequency monitors at the following resolutions and
maximum refresh rates (Hz).
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
Aspect Ratio Bits Per Pixel
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 100
5 x 4 100
Vertical Refresh Rates (Hz)
60, 72, 75, 85, 60i
60, 72, 75, 85, 60i
60, 70, 75, 85, 60i
60, 70, 75, 85, 60i
60, 75, 85, 60i
60, 75, 85, 60i
13
