Technical Information

The following information is subject to change without notice.

Hardware Specifications

Item
System
Board Size
Interrupts
Power Requirements

Monitor Resolutions

Intense 3D Pro 2200S supports standard multi-sync monitors, including
Intergraph 17-inch and 21-inch multi-sync monitors, at the following
resolutions and maximum refresh rates (Hz). Note that i indicates an
interlaced frequency.
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
Specification
PCI Local Bus Standard 2.1
12.25 in x 3.875 in; full-length PCI board
PCI-assigned -- Interrupt A for Intense 3D
+12V 220 mA
12V 30 mA
+5V 0.87 A
+3.3V 4.8 A
Aspect Bits Per
Ratio Pixel
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 100
5 x 4 100
Vertical Refresh Rates (Hz)
60, 72, 75, 85, 60i
60, 72, 75, 85, 60i
60, 70, 75, 85, 60i
60, 70, 75, 85, 60i
60, 75, 85, 60i
60, 75, 85, 60i
