Technical Information

The following technical information is subject to change without notice.

Hardware Specifications

Item
System
Card Sizes
Interrupts

Monitor Resolutions

In the following tables, i indicates an interlaced frequency.
Intense 3D Wildcat 4000 supports standard multi-sync monitors, including Intergraph 17-inch
and 21-inch multi-sync monitors, at the following resolutions and maximum refresh rates (Hz).
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
Intense 3D Wildcat 4000 supports Intergraph InterView-20, InterView-21, and InterView-27
monitors at the following resolutions and maximum refresh rates (Hz).
Resolution
640 x 480
800 x 600
1024 x 768
1280 x 960
1280 x 1024
Specification
PCI Local Bus Standard 2.1 and AGP 2.0
12.25 in x 3.875 in full-length AGP card
12.25 in x 3.875 in full-length PCI card
PCI-assigned -- Interrupt A for Intense 3D
Aspect Ratio Bits Per Pixel
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 100
5 x 4 100
Aspect Ratio Bits Per Pixel
4 x 3 128
4 x 3 128
4 x 3 128
4 x 3 100
5 x 4 100
Vertical Refresh Rates (Hz)
60, 72, 75, 85, 60i
60, 72, 75, 85, 60i
60, 70, 75, 85, 60i
60, 70, 75, 85, 60i
60, 75, 85, 60i
60, 75, 85, 60i
Vertical Refresh Rates (Hz)
154 (20), 185 (21), 151 (27)
126 (20), 153 (21), 123 (27)
99 (20), 122 (21), 98 (27)
81 (20), 79 (27)
76 (20), 72i (20), 74 (27), 70i (27)
13
