Summary of Contents for Intergraph Intense 3D Pro 3600
- Page 1 Intense 3D Pro 3600 Installation Guide October 1998 DHA032400...
- Page 2 Intergraph Computer Systems. Intergraph Computer Systems shall not be liable for technical or editorial errors in, or omissions from, this document. Intergraph Computer Systems shall not be liable for incidental or consequential damages resulting from the furnishing or use of this document.
- Page 3 Notes This device is designed and manufactured to comply with approved safety standards for information processing and business equipment. Read all operating instructions before using this device. Keep these instructions for future reference. Follow all warnings on the device or in the operating instructions.
- Page 5 Introduction Congratulations! In choosing Intense 3D Pro 3600, you are equipping your personal computer or personal workstation with powerful and professional 3D graphics. Intense 3D Pro 3600 infuses Intel Pentium Pro and Pentium II computers running the Microsoft Windows NT operating system with workstation-class 3D graphics features and performance.
-
Page 6: Hardware Requirements
Multiple screens (up to four) One PCI slot per screen Software Intense 3D Pro 3600 uses the Intense 3D video display driver. The video display driver installs as a standard Windows NT driver, and provides both GDI and OpenGL graphics compatibility. -
Page 7: Preparing For Installation
Preparing for Installation Follow these instructions to prepare your computer for Intense 3D Pro 3600. Make Sure Your Computer Is Ready Make sure your IBM PC-compatible computer has the following: A Pentium Pro or Pentium II processor. A high-resolution multi-sync analog RGB monitor. Windows NT 4.0 operating system. -
Page 8: Collect Materials And Tools
3600 hardware in its original packaging to obtain warranty service. Make a Copy of the Video Display Driver Diskettes Make a copy of the diskettes containing the Intense 3D Pro 3600 video display driver as a precaution. Should anything happen to the copy, you will still have the original diskettes. -
Page 9: Installing The Hardware
4. Select the slots into which you will install the Intense 3D Pro 3600 card. Select one open PCI slot for each Intense 3D Pro 3600 card you want to install. 5. Remove the slot covers from the selected slots. Retain the screws from the slot covers;... -
Page 10: Finish The Installation
To finish the installation: 1. Close the computer. 2. Connect the computer monitor’s video cable to the blue video output port on the Intense 3D Pro 3600 card. See the following figure. If you installed multiple cards for multiple screens, connect a video cable from each computer monitor to the blue video output port on each card. - Page 11 When you start the system and log onto a system with multiple screens, you may have to switch the cable connections to the Intense 3D Pro 3600 cards if the screen display is not correct. For example, in a side-by-side monitor configuration, if the right half of...
-
Page 13: Installing The Software
When you start the system and log onto a system with m ultiple screens, you may have to switch the cable connections to the Intense 3D Pro 3600 cards if the screen display is not correct. For example, in a side-by-side dual-screen monitor configuration, if the... -
Page 14: Configure The Video Display
For more detailed installation information, refer to the README file delivered on the diskette containing the Intense 3D Pro 3600 video display driver. Configure the Video Display Open Display in the Control Panel to view the Display Properties dialog. -
Page 15: Activate Multi-Screen Behavior
3. Click OK to close the System dialog. NOTE Do not select the VGA version of the operating system. The video display runs in VGA mode when the Intense 3D Pro 3600 driver is not running. Activate Multi-Screen Behavior If your computer is configured for multi-screen display (with multiple Intense 3D Pro 3600 cards installed), the video display driver treats the combined display area as a single canvas that covers all screens. -
Page 17: Technical Information
Technical Information The following Intense 3D Pro 3600 information is subject to change without notice. Hardware Specifications Item Specification System PCI Local Bus Standard 2.1 Card Size 12.25 in x 3.875 in; full-length PCI card Interrupts PCI-assigned -- Interrupt A for Intense 3D... -
Page 18: Vga Video Display Support
1440 x 900 16 x 10 60, 75, 85 VGA Video Display Support The Intense 3D Pro 3600 card provides onboard VGA video display support. The maximum resolution supported is 800 x 600, 4 bits per pixel, at 60 Hz vertical refresh. -
Page 19: Texture Processing
Interfaces The Intense 3D Pro 3600 cards have two interfaces: a video output port and a stereo sync output port. These interfaces are described in the following sections. - Page 20 Video Output Port The video output port is a blue, female, 15-pin, D-Sub connector. The port provides connection to a computer monitor. The recommended cable length is less than three meters. Signal Name Signal Name Red Analog Video +5V Supply Green Analog Video Ground Blue Analog Video...
- Page 21 Stereo Sync Output Port The stereo sync output port is a female, 5-pin, mini-DIN connector. The port provides connection to the emitter module of a pair of LCD shutter glasses. Signal Name Ground Ground +12V Stereo Sync No Connect...
