5. Select the Signal Edge Response, Signal Lock Rate, and Pixel Align Offset appropriate for
your application and hardware setup, and then click Apply.
NOTE Some monitors require custom timing file entries for Genlock to be properly
maintained. Refer to the documentation delivered with your monitor for further
information.

Enabling Dual Monitors in Windows 2000

Wildcat 4210 supports dual monitors on a computer running Windows 2000. Two monitors can
be connected to the Wildcat 4210 so the display area stretches across both monitors.
NOTE Before enabling dual monitors, connect the second monitor to the Secondary DVI-I
port. See Chapter 1, "Setup," for instructions.
To enable dual monitors:
1. From the operating system Start menu, go to Settings » Control Panel » Display » Settings »
Advanced » Intense3D Configuration.
2. Next to Maximum Number of Displays, select 2, and then click Apply (see Figure 13).
Figure 13. Choosing Maximum Number of Displays
3. When prompted, click Yes to shut down the computer. When the computer has shut down,
turn off power to the computer.
4. Turn on power to the computer and to the monitors. The primary monitor displays the startup
sequence. If the monitors' Power On LEDs do not illuminate or the monitors do not display,
refer to Chapter 4, "Troubleshooting."
